A1 A3 A4 A5 B3
An affordable desktop with incredible upgrade potential.

Chassis: Lancool PC-K7B Black


Main System Picture
  • Color: Black
  • Material: Aluminum front panel, steel frame
  • Type/Size: Mid Tower
  • Case Window: No

Dimensions
  • Height: 460 mm (18.1 inches)
  • Width: 210 mm (8.3 inches)
  • Depth: 489 mm (19.3 inches)

Front Panel Connections:
  • USB 2.0: 2
  • Firewire: 1
  • Audio In: 1
  • Audio Out: 1



Motherboard: Asus M5A88-V EVO


Processing
  • Socket: AM3+
  • CPU: AMD AM3+ FX™/Phenom™ II/Athlon™ II/Sempron™ 100 Series Processors
  • Form Factor: MicroATX
  • Chipset: AMD 880G/SB850

Expansion Slots:
  • Slot 1: PCI Express 2.0 x1
  • Slot 2: PCI Express 2.0 x16
  • Slot 3: PCI
  • Slot 4: PCI
  • Slot 5: PCI Express x4 in a x16 size
  • Slot 6: PCI

Memory:
  • Type: DDR3 1333 MHz
  • Number of Slots: 4
  • Max per Slot: 4 GB
  • Max Supported: 16 GB

Connections:
  • Rear USB 2.0: 4
  • Rear USB 3.0: 2
  • Rear Firewire: 1


Back Ports Picture

Back Ports:


  1. PS/2 Hybrid Port
  2. Optical S/PDIF Out
  3. VGA Out Port
  4. USB 2.0 Port(s)
  5. Gigabit LAN Port (RJ-45)
  6. USB 2.0 Port(s)
  7. HDMI Out Port
  8. DVI Out Port
  9. Firewire Port (IEEE 1394a)
  10. External SATA Port
  11. USB 3.0 Ports
  12. Audio Jacks
 Picture Gallery


Power Draw:

Spirit
Deluge
Genesis
Serenity
Obsidian
Echo

Noise Level:

Spirit
Deluge
Genesis
Serenity
Obsidian
Echo
