Designed for use with Mini ITX motherboards, the Silverstone SG05 is the smallest Sugo yet. However, in keeping with the spirit of its Sugo name, the case is capable of swallowing many standard components while keeping everything cooled. For the first time in a case of this size class, the SG05 is equipped with a low speed 120mm fan that is mounted to create positive air pressure, ensuring good balance of cooling and quietness. Other notable features include the ability to accept 10 inch long graphics card, room for both a 2.5-inch solid-state drive and a traditional 3.5-inch hard drive, and sufficient space for stock or low-profile CPU coolers.
This version of the SG05 updates both of the front ports to USB 3.0 specifications. This requires a motherboard with an internal USB 3.0 header in order to function - or if that is not present, we carry USB 3.0 expansion cards which can fill the needed role. No power supply is included in the "LITE" edition.
This version of the SG05 updates both of the front ports to USB 3.0 specifications. This requires a motherboard with an internal USB 3.0 header in order to function - or if that is not present, we carry USB 3.0 expansion cards which can fill the needed role. No power supply is included in the "LITE" edition.
Model: Silverstone SST-SG05BB-LITE
Specifications
Dimensions | |
Height | 176 mm (6.9 in) |
Width | 222 mm (8.7 in) |
Depth | 276 mm (10.9 in) |
Maximum CPU Cooler Height | 82mm |
Maximum GPU Length | 10in |
Drive Bays | |
Internal 3.5 inch | 1 |
Internal 2.5 inch | 1 |
Slim 5.25 inch | 1 |
Front Panel Connectors | |
USB 3.0 | 2 |
Audio In | 1 |
Audio Out | 1 |
Cooling System | |
Included Fans | 1 x 120mm |
Case without power supply
