Noctua NH-U9 TR4-SP3
CPU Cooling
The Noctua NH-U9S TR4-SP3 is a high-end heatsink and fan cooling system for AMD's TR4 socket, which is used by the Threadripper CPU platform. The pair of compact 92mm fans which are mounted to this cooler reduce the overall height dramatically when compared to 120 and 140mm models. That smaller size allows use of this heatsink in 4U rackmount cases, which wouldn't be possible with larger fans.
William George (Product Development) Says:
Please note that when building AMD Threadripper rackmount systems we replace the stock Noctua fans on this cooler with higher airflow models from Everflow. That increases noise substantially, but then stock 4U rackmount case fans are not quiet to begin with anyhow.
Please note that when building AMD Threadripper rackmount systems we replace the stock Noctua fans on this cooler with higher airflow models from Everflow. That increases noise substantially, but then stock 4U rackmount case fans are not quiet to begin with anyhow.
Note: Noctua fans are replaced with high-speed Cooljag fans to provide adequate cooling
Model: Noctua NH-U9 TR4-SP3
Specifications:
Specifications:
| Dimensions | |
| Length | 120 mm (4.7 in) |
| Width | 95 mm (3.7 in) |
| Height | 125 mm (4.9 in) |
| Net Weight | 0.895 kg (2.0 lbs) |
| Fan Specifications | |
| Air Flow | 15.74-67.9 CFM |
| Bearing | Dual Ball Bearing |
| Fan Size | 92 mm (3.6 in) |
| Fan Speed | 800-3450 RPM |
| Noise Level | 19-40.7 dBa |
| Static Pressure | .3-5.5 mmAq |
| General | |
| Compatibility | AMD Threadripper |
Configure a custom computer with the Noctua NH-U9 TR4-SP3.
