Intel Core i7 9700KF 3.6GHz Eight Core 12MB 95W

CPU

Intel Core i7 9700KF 3.6GHz Eight Core 12MB 95W Picture 52839

Background on Intel 9th Gen Core Series CPU (Coffee Lake)

9th Gen Intel Core Processors are a refresh of their Coffee Lake architecture, increasing both core count and clock speed over the previous generation. These processors have inherited and refined Intel's 14nm manufacturing process, and feature better thermal interface material as well. It is also the first time that Intel is using the Core i9 marketing name in a mainstream processor line, as the top-end model in this series. There are also Core i7 and i5 models, with lower-end i3 chips coming later on.

For details about performance in different applications, check out our many processor (CPU) articles.


This is a variant of the Core i7 9700K, just without onboard graphics. It can be used in a system with a dedicated GPU with little loss of functionality, making it a great alternative to the normal version in case of manufacturing shortages.
Model: Intel BX80684I79700KF

Specifications:
spacer
Product Line  Core i7
Code Name  Coffee Lake
Socket  1151
Process  14 nm
Number of Cores  8
Clock Speed  3.6 GHz
Hyperthreading  No
Turbo Boost  Yes
Max. Turbo Boost  4.9 GHz
All-Core Turbo Boost  4.6 GHz
Bus Type  DMI3
Thermal Output  95 W
PCI-E Lanes  16
Cache
Smart Cache  12MB
Onboard Graphics
Processor Type  None
Memory Specification
Memory Type  DDR4
Maximum Frequency  2666
ECC Support  No
Advanced Technologies
vPro  Yes
Virtualization Technology (VT-x)  Yes
Virtualization Technology for Directed I/O (VT-d)  Yes
Trusted Execution Technology  Yes
TSX-NI  Yes


Configure a custom computer with the Intel Core i7 9700KF 3.6GHz Eight Core 12MB 95W.
