Intel Core i9 12900KS 3.4GHz 16 Core 30MB 150W

CPU

Intel Core i9 12900KS 3.4GHz 16 Core 30MB 150W Picture 72790

Background on Intel 12th Gen Core Series CPUs (Alder Lake)

12th Gen Intel Core Processors, code named Alder Lake, are a refresh of their consumer CPU line with improvements to both overall core count and per-core performance. These chips are built using Intel's 7nm manufacturing process, which saves a lot of space compared to previous generations and thus allows for more circuitry to be packed into the die. Intel has used that space savings to introduce the idea of additional "efficiency cores", which run at a lower clock speed and allow for background tasks to be offloaded from the main "performance cores". Alternatively, in a heavily threaded application, both sets of cores can work together to improve overall processing speed.

For details about performance in different applications, check out our many processor (CPU) articles.


William George (Product Development)
William George (Product Development) Says:
This is a slightly faster chip than the normal Core i9 12900K, with higher power limits to go along with that. In general, it will be a few percent faster - but since the price isn't a big jump (in the grand scheme of a whole workstation) that is probably worthwhile to many users.
Model: Intel CM8071504569915

Specifications:
spacer
Product Line  Core i9
Code Name  Alder Lake
Socket  1700
Process  7 nm
Total Number of Cores  16
Number of Efficient Cores  8
Base Clock Speed  3.40 GHz
Efficient Core Base Clock Speed  2.50 GHz
Hyperthreading  Yes
Turbo Boost  Yes
Max. Turbo Boost  5.50 GHz
Efficient Core Max Turbo Boost  4.00 GHz
Bus Type  DMI4
QPI Speed  16 GT/s
Thermal Output  150 W
PCI-E Lanes  20
Max Temperature  100 C
Cache
L2  14MB
Smart Cache  30MB
Onboard Graphics
Processor Type  Intel UHD Graphics 770
Core Speed  1,550 MHz
DirectX Version  12
Cores on Die  32
# of Displays Supported  4
Memory Specification
Memory Type  DDR5
Maximum Frequency  4800
Advanced Technologies
Virtualization Technology (VT-x)  Yes
Virtualization Technology for Directed I/O (VT-d)  Yes


Configure a custom computer with the Intel Core i9 12900KS 3.4GHz 16 Core 30MB 150W.
