Intel Xeon E5-2650 2.0GHz Eight Core 20MB 95W

CPU

Intel Xeon E5-2650 2.0GHz Eight Core 20MB 95W Main Picture


Model: Intel BX80621E52650

Specifications

Product Line Xeon
Code Name Sandy Bridge-EP
Socket 2011
Process 32 nm
Total Number of Cores 8
Base Clock Speed 2.0 GHz
Hyperthreading Yes
Turbo Boost Yes
Max. Turbo Boost 2.8 GHz
Thermal Output 95 W
Bus Type QuickPath Interconnect
Cache
L2 8 x 256KB
Smart Cache 20MB
Memory Specification
Memory Type DDR3
Maximum Frequency 1600
ECC Support Yes
Advanced Technologies
vPro Yes
Virtualization Technology (VT-x) Yes
Virtualization Technology for Directed I/O (VT-d) Yes
Trusted Execution Technology Yes

There is currently a bug in the Windows 7 Experiance Index tool where it is unable to complete the system performance assessment due to an error of "Could not measure system memory performance". This occurs because WEI detects the CPU cache size (20MB) and doubles the cache size value as the input parameter of the buffer size (40MB). The tool is limited to support a buffer size of 32MB, so a buffer larger than this size causes an error. This has only been found to affect WEI and should not impact system performance.
