Intel Xeon E7-8867 V4 2.4GHz Eighteen Core 45MB 165W


Intel Xeon E7-8867 V4 2.4GHz Eighteen Core 45MB 165W Picture 39871

Background on Intel Xeon E7 v4 CPU

Intel's E7 v4 series of Xeon processors are based on the Broadwell EX architecture, and utilize the same socket 2011 for mounting. These are the top-end of the modern Xeon line in terms of the number of supported CPUs in a single system, allowing for 4-way or 8-way operation... though the motherboard we use here at Puget is limited to 4 physical CPUs. Still, that allows for up to 96 actual processing cores - or 192 threads, thanks to Intel's Hyperthreading technology.

Quad-channel DDR4 memory per CPU is supported, just as with the dual processor Xeons, allowing for massive amounts of RAM and high memory bandwidth to keep all those cores fed with data. The size of motherboard required to fit four sockets and the accompanying RAM slots means that only the largest cases can fit a system built on this architecture.

Please note that due to the rarity of these processors, some will require an additional 4 to 6 week lead time for orders using them. Please work with one of our consultants if you need assistance or have any questions!

Model: Intel CM8066902028403

Product Line  Xeon
Code Name  Broadwell-EX
Socket  2011
Process  14 nm
Number of Cores  18
Clock Speed  2.4 GHz
Hyperthreading  Yes
Turbo Boost  Yes
Max. Turbo Boost  3.3 GHz
All-Core Turbo Boost  2.8 GHz
Bus Type  QuickPath Interconnect
QPI Speed  9.6 GT/s
Thermal Output  165 W
PCI-E Lanes  32
Smart Cache  45MB
Memory Specification
Memory Type  DDR4
Maximum Frequency  1866
ECC Support  Yes
Advanced Technologies
vPro  Yes
Virtualization Technology (VT-x)  Yes
Virtualization Technology for Directed I/O (VT-d)  Yes
Trusted Execution Technology  Yes


1 Year

  • Intel Xeon E7-8867 V4 2.4GHz Eighteen Core 45MB 165W Utility

Configure a custom computer with the Intel Xeon E7-8867 V4 2.4GHz Eighteen Core 45MB 165W.
