AMD Radeon R9 290X 4GB

Video Card

AMD Radeon R9 290X 4GB Picture 25682AMD Radeon R9 290X 4GB Picture 25680AMD Radeon R9 290X 4GB Picture 25681
Model: AMD R9 290X

Chipset Manufacturer  AMD
Product Line  Radeon
Motherboard Connection  PCI Express 3.0 x16
Maximum HDMI Resolution  4096x2160
Maximum DisplayPort Resolution  4096x2160
Maximum DVI Resolution  2560x1600
Maximum Monitors Supported  6
HDCP Compliant  Yes
GPU Specifications
Core Speed  1000 MHz
Stream Processors  2816
Memory Specifications
Video Memory  4GB
Memory Type  GDDR5
Memory Speed  5000 MHz
Memory Bus Width  512-bit
Bandwidth  352 GB/s
Additional Information
Cooling System  Blower Type
DirectX Support  DirectX 12
OpenGL Support  4.3
Port 1  Dual-Link DVI
Port 2  Dual-Link DVI
Port 3  HDMI
Port 4  DisplayPort
Power Connectors
Plug 1  6-pin PCI-E
Plug 2  8-pin PCI-E
Length  284 mm (11.2 in)
Height  144.8 mm (5.7 in)
Width  38.1 mm (1.5 in)

Maximum Displays: 3 with DVI/HDMI, 4 using DisplayPort, 6 with an MST hub

with the AMD Radeon R9 290X 4GB.
