AMD's Radeon R9 390 is a refresh to the previous R9 290, with the core clock speed slightly increased to boost performance - and with double the memory as well. The speed increase puts it just a hair faster than the card it replaces, and the added VRAM will help with game performance at high resolution. Like most other Radeon cards in the 200- and 300-series, the R9 390 supports several GPU technologies: Eyefinity, Crossfire, Mantle, DirectX 12, OpenGL, OpenCL Accelerated Parallel Processing, the Havok physics engine, and 3D Blu-ray movies.
This specific Asus version of the R9 390 has a dual fan cooler for increased cooling capacity at a lower noise level. A potential drawback to this design is that it exhausts hot air into the chassis instead of out the back of the system, which means it can cause a slight temperature increase to other nearby components (CPU, chipset, etc). For display output, two DVI, one HDMI, and one DisplayPort are present.
This specific Asus version of the R9 390 has a dual fan cooler for increased cooling capacity at a lower noise level. A potential drawback to this design is that it exhausts hot air into the chassis instead of out the back of the system, which means it can cause a slight temperature increase to other nearby components (CPU, chipset, etc). For display output, two DVI, one HDMI, and one DisplayPort are present.
Model: Asus STRIX-R9390-DC3OC-8GD5-GAMING
Specifications
Chipset Manufacturer | AMD |
Product Line | Radeon |
Interface | PCI Express 3.0 x16 |
Maximum Digital Resolution | 4096x2160 |
Maximum Monitors Supported | 6 |
HDCP Compliant | Yes |
GPU Specifications | |
Boost Speed | 1050 Mhz |
Stream Processors | 2560 |
Memory Specifications | |
Video Memory | 8GB |
Memory Type | GDDR5 |
Memory Speed | 6000 MHz |
Memory Bus Width | 512-bit |
Bandwidth | 384 GB/s |
Additional Information | |
Cooling System | Open Air Type |
DirectX Support | DirectX 12 |
OpenGL Support | 4.4 |
Outputs | |
Port 1 | Dual-Link DVI |
Port 2 | DisplayPort |
Port 3 | HDMI |
Port 4 | DisplayPort |
Port 5 | DisplayPort |
Power Connectors | |
Plug 1 | 6-pin PCI-E |
Plug 2 | 8-pin PCI-E |
Dimensions | |
Length | 300 mm (11.8 in) |
Height | 137.7 mm (5.4 in) |
Width | 40 mm (1.6 in) |
Maximum Displays: 6 with an MST hub
