Specifications
| Form Factor | Socket 478 |
| Chipset | VIA P4M266 |
Memory Type: PC2100
Max CPU: 2600
Max Memory: 2 GB
Memory Slots: 2
AGP: 4x
# PCI: 1
9.5in(H) x 8.3in(W) x 12in(D)
- VIA P4M266 chipset
- Winbond W83627HF LPC controller
- Supports Intel Socket 478 - Pentium 4 processors: (1.4GHz ~ 2.4GHz)
- Support 2x 184-pin DDR200/266 SDRAM up to 2GB
- Onboard S3 ProSavage8 DDR 2D/3D graphics - 4 to 32MB frame buffer using system memory - VT1621 TV Encoder, TV-out supported, S-Video port and composite TV-out
- Onboard IR port
- Onboard Realtek 10/100 Fast Ethernet- support PXE and RPL Protocol.
- Onboard USB 2.0 interface (4 ports)
- Onboard AC'97 v2.2 audio ports
- Supports ATA/133 ATA-6 IDE interface
