Model: Asus M3A
Specifications
| Socket | AM2+ |
| CPU Compatibility | AMD Phenom, Athlon 64 |
| Form Factor | ATX |
| Chipset Manufacturer | AMD |
| Chipset | AMD 770 / SB600 |
| Front Side Bus | 2600Mhz HT |
| Wired Network Connectivity | Gigabit Networking |
| Cooling System | Heatsink |
| Number of Fans | 0 |
Memory Support | |
| Type | DDR2 |
| Maximum Speed | 1066 MHz |
| Number of Slots | 4 |
| Maximum Size per Slot | 2 GB |
| Maximum Amount Supported | 8 GB |
External Connections | |
| USB 2.0 | 4 |
| PS/2 Mouse | Yes |
| PS/2 Keyboard | Yes |
| Audio Out | Surround Sound (7.1) |
| Audio In | Line-In/Microphone |
| S/PDIF | Coaxial |
| LAN (RJ45) | 1 |
| Serial (COM) Port | 1 |
Internal Connections | |
| USB 2.0 | 3 (providing 6 ports) |
| Floppy | 1 |
| IDE | 2 Devices |
Expansion Slots | |
| Slot 1 | PCI Express x16 |
| Slot 2 | PCI Express x1 |
| Slot 3 | PCI |
| Slot 4 | PCI Express x1 |
| Slot 5 | PCI |
| Slot 6 | PCI |
Additional Information | |
| SLI Compatible | No |
| Crossfire Compatible | No |
| RAID Support | 0/1/0+1 |
Internal Connections
SATA2: 4
UPC 0610839156696
