Model: Asus M3N78-VM
Specifications
| Socket | AM2+ |
| CPU Compatibility | Athlon64, Phenom |
| Form Factor | MicroATX |
| Chipset Manufacturer | nVidia |
| Chipset | GeForce 8200 |
| Front Side Bus | 2600Mhz HT |
| Wired Network Connectivity | Gigabit Networking |
| Cooling System | Heatsink |
Memory Support | |
| Type | DDR2 |
| Maximum Speed | 1066 MHz |
| Number of Slots | 4 |
| Maximum Size per Slot | 2 GB |
| Maximum Amount Supported | 8 GB |
Onboard Video | |
| Chipset Manufacturer | nVidia |
| Processor Type | GeForce 8200 |
| DVI | 1 |
| VGA | 1 |
| HDMI | 1 |
| Notes: | HDMI or DVI can be active (not both), along with VGA |
External Connections | |
| USB 2.0 | 5 |
| PS/2 Mouse | No |
| PS/2 Keyboard | Yes |
| Audio Out | Surround Sound (7.1) |
| Audio In | Line-In/Microphone |
| S/PDIF | Optical |
| External SATA | 1 |
Internal Connections | |
| USB 2.0 | 3 (providing 6 ports) |
| Floppy | 1 |
| IDE | 2 Devices |
Expansion Slots | |
| Slot 1 | PCI Express x1 |
| Slot 2 | PCI Express x16 |
| Slot 3 | PCI |
| Slot 4 | PCI |
Internal Connections
SATA2: 5
