Model: Asus P5N7A-VM
Specifications
| Socket | 775 |
| CPU Compatibility | Core 2 Duo, Core 2 Quad |
| Form Factor | MicroATX |
| Chipset Manufacturer | nVidia |
| Chipset | GeForce 9300 / nForce 730i |
| Front Side Bus | 1333Mhz |
| Wired Network Connectivity | Gigabit Networking |
| Cooling System | Heatsink |
Memory Support | |
| Type | DDR2 |
| Maximum Speed | 800 MHz |
| Number of Slots | 4 |
| Maximum Size per Slot | 4 GB |
| Maximum Amount Supported | 16 GB |
Onboard Video | |
| Chipset Manufacturer | nVidia |
| Processor Type | GeForce 9300 |
| Maximum Shared Memory | 512 MB |
| DVI | 1 |
| VGA | 1 |
| HDMI | 1 |
| Notes: | Has Display Port; HDCP compliant |
External Connections | |
| USB 2.0 | 6 |
| PS/2 Keyboard | Yes |
| PS/2 Mouse | No |
| Audio Out | Surround Sound (7.1) |
| Audio In | Line-In/Microphone |
| S/PDIF | Optical |
| External SATA | 1 |
| LAN (RJ45) | 1 |
Internal Connections | |
| USB 2.0 | 3 (providing 6 ports) |
| IDE | 2 Devices |
Expansion Slots | |
| Slot 1 | Slot not available on this board |
| Slot 2 | Slot not available on this board |
| Slot 3 | Slot not available on this board |
| Slot 4 | PCI |
| Slot 5 | PCI |
| Slot 6 | PCI Express x16 |
| Slot 7 | PCI Express x1 |
Additional Information | |
| SLI Compatible | No |
| Crossfire Compatible | No |
Dimensions | |
| Height | 244 mm (9.6 in) |
| Width | 234 mm (9.2 in) |
Internal Connections
SATA2: 5
