Asus P5Q-EM

Motherboard

[ Rear Ports ][ Schematic ]

Asus P5Q-EM Picture 12524Asus P5Q-EM Picture 12522Asus P5Q-EM Picture 12523Asus P5Q-EM Picture 12525Asus P5Q-EM Picture 12526Asus P5Q-EM Picture 12648Asus P5Q-EM Picture 12649

Note: any double slot graphics card exceeding 8" may block Sata ports.

Model: Asus P5Q-EM

Specifications:
spacer
Socket  775
CPU Compatibility  Quad-core / Core 2 Extreme / Core 2 Duo / Pentium
Form Factor  MicroATX
Chipset Manufacturer  Intel
Chipset  G45
Front Side Bus  1600Mhz
Network Connectivity  Gigabit Networking
Cooling System  Heatsink
Memory Support
Type  DDR2
Maximum Speed  800 MHz
Number of Slots  4
Maximum Size per Slot  4 GB
Maximum Amount Supported  16 GB
Onboard Video
Chipset Manufacturer  Intel
Processor Type  GMA X4500HD
Maximum Shared Memory  1849 MB
Maximum Resolution  2048 x 1536
DVI  1
VGA  1
HDMI  1
External Connections
USB 2.0  6
Firewire  1
PS/2 Keyboard  Yes
PS/2 Mouse  No
Audio Out  Surround Sound (7.1)
Audio In  Line-In/Microphone
S/PDIF  Optical
LAN (RJ45)  1
Internal Connections
USB 2.0  3 (providing 6 ports)
Firewire  1
Floppy  1
IDE  2 Devices
Expansion Slots
Slot 1  PCI Express x1
Slot 2  PCI Express 2.0 x16
Slot 3  PCI Express x1
Slot 4  PCI
Additional Information
SLI Compatible  No
Crossfire Compatible  No
RAID Support  0/1/5/10
Dimensions
Height  244 mm (9.6 in)
Width  244 mm (9.6 in)

Internal Connections
SATA2: 6
