Asus Pro WS WRX90E-SAGE SE

Motherboard

Asus Pro WS WRX90E-SAGE SE Main Picture


Asus Pro WS WRX90E-SAGE SE Picture 82754Asus Pro WS WRX90E-SAGE SE Picture 82755Asus Pro WS WRX90E-SAGE SE Picture 82756Asus Pro WS WRX90E-SAGE SE Picture 82757
The ASUS Pro WS WRX90E-SAGE SE is a large, SSI EEB size motherboard for AMD's Threadripper PRO 7000 Series processors. In addition to the sWRX9 socket for the CPU, it has eight RAM slots supporting DDR5 Registered ECC memory and seven PCI-Express 5.0 x16 slots (one of which is functionally only x8). That layout allows for a very diverse configuration of expansion cards, limited only by space inside the chassis, cooling / airflow, and power availability. Because of its size, though, only certain full-size tower and rackmount cases can fit this board.

A wide range of connectivity is provided as well: six USB 3.2 ports, two of the new USB 4.0 Type C ports, dual 10Gb Ethernet, and analog audio. Internally it supports a wide array of storage options with four SATA ports, four M.2 slots, and two SlimSAS connectors.

Model: Asus Pro WS WRX90E-SAGE SE

Specifications

Socket sWRX9
CPU Compatibility Threadripper Pro 7000
Form Factor SSI EEB
Chipset Manufacturer AMD
Chipset WRX90
Network Connectivity Dual 10G Networking
Network Controller Intel
Audio Controller Onboard Realtek ALC1220P HD Audio
Cooling System Heatsink and Fan
Number of Fans 3
Color Black
Memory Support
Type DDR5 ECC Registered
Maximum Speed 5200 MHz
Number of Slots 8
Maximum Size per Slot 256 GB
Maximum Amount Supported 2048 GB
Onboard Video
Chipset Manufacturer ASpeed
Processor Type AST2600
Maximum Resolution 1920x1200
VGA 1
USB 4.0
Notes: Displayport IN for USB 4 video support
External Connections
USB 2.0 1
USB 3.2 Gen 2 (USB 3.1) 6
USB 4 2
PS/2 Keyboard No
PS/2 Mouse No
Audio Out Stereo
Audio In Line-In/Microphone
LAN (RJ45) 2
Mgmt LAN (RJ45) 1
Wireless Antenna Port No
BIOS Flashback Yes
Internal Connections
USB 2.0 2 (providing 4 ports)
USB 3.2 Gen 1 (USB 3.0) 1
USB 3.2 Gen 2x2 Type C 1
SATA III 6.0Gbps 4
M.2 Connector 4
M.2 Support 2x 42-110mm PCIe 5.0, 2x 42-80mm PCIE 5.0
U.2 Connector 2
Serial (Com) 1
TPM (module sold separately) 1
Compatible TPM Asus TPM-SPI
SlimSAS 2
Notes: SlimSAS Supports PCIe 4.0 x4
SATA Controllers
SATA III 6.0Gbps Controller 1 AMD WRX90
SATA III 6.0Gbps Controller 2 Asmedia
Expansion Slots
Slot 1 PCI Express 5.0 x16
Slot 2 PCI Express 5.0 x16
Slot 3 PCI Express 5.0 x16
Slot 4 PCI Express 5.0 x16
Slot 5 PCI Express 5.0 x16
Slot 6 PCI Express 5.0 x8 in a x16 size
Slot 7 PCI Express 5.0 x16
Additional Information
SLI Compatible No
Crossfire Compatible No
RAID Support 0, 1, 10
Integrated IO Shield Yes
Remote Management Onboard
BIOS Features
UEFI BIOS Yes
EZ Flash Yes
OC Profiles Yes
Dimensions
Height 310 mm (12.2 in)
Width 330 mm (13.0 in)
Net Weight 2.5 kg (5.5 lbs)
