Asus Z9PE-D16/2L (w/ ASMB6-IKVM) Ports
PS/2 Mouse Port: Connection for a PS/2 mouse.
iKVM LAN Port (RJ-45): RJ-45 plug for remote management of computer via iKVM (Keyboard/Video/Mouse over IP).
LAN Port (RJ-45): RJ-45 plug for connecting to a wired Local Area Network (LAN) via Ethernet at up to 100 Mbps.
LAN Port (RJ-45): RJ-45 plug for connecting to a wired Local Area Network (LAN) via Ethernet at up to 100 Mbps.
PS/2 Keyboard Port: Connection for a PS/2 keyboard.
USB 2.0 Port(s): Universal Serial Bus (USB) port for connecting USB 2.0 and older devices (480 Mb/s).
VGA Out Port: Video Graphics Adapter (VGA) port for outputting analog video.
Asus Z9PE-D16/2L (w/ ASMB6-IKVM) Schematic
Note: As this is a server motherboard, some desktop features are not present: specifically, standby/sleep functionality is not guaranteed.
Model: Asus Z9PE-D16/2L(ASMB6-IKVM)
Specifications
| Socket | Dual 2011 |
| CPU Compatibility | Intel Xeon E5-2600 Family |
| Form Factor | EATX |
| Chipset Manufacturer | Intel |
| Chipset | C602-A PCH |
| Front Side Bus | QuickPath Interconnect |
| Wired Network Connectivity | Dual Gigabit Networking |
| Network Controller | Intel i350-AM2 |
| Cooling System | Heatsink |
| Color | Green |
Memory Support | |
| Type | DDR3 ECC Registered |
| Maximum Speed | 1600 MHz |
| Number of Slots | 16 |
| Maximum Size per Slot | 32 GB |
| Maximum Amount Supported | 512 GB |
Onboard Video | |
| Processor Type | Aspeed AST2300 |
| VGA | 1 |
External Connections | |
| USB 2.0 | 2 |
| PS/2 Keyboard | Yes |
| PS/2 Mouse | Yes |
| LAN (RJ45) | 2 |
| Mgmt LAN (RJ45) | 1 |
Internal Connections | |
| USB 2.0 | 2 (providing 4 ports) |
| SATA II 3.0Gbps | 8 |
| SATA III 6.0Gbps | 10* |
| Serial (Com) | 2 |
SATA Controllers | |
| SATA II 3.0Gbps Controller 1 | 4 port - Intel C602-A AHCI |
| SATA II 3.0Gbps Controller 2 | 4 port - Intel C602-A SCU |
| SATA III 6.0Gbps Controller 1 | 2 port - Intel C602-A AHCI |
| SATA III 6.0Gbps Controller 2 | 8 port - ASUS PIKE* |
Expansion Slots | |
| Slot 1 | PCI Express 3.0 x8 in a x16 size |
| Slot 2 | PCI Express 3.0 x16 |
| Slot 3 | PCI Express 3.0 x16 |
| Slot 4 | PCI Express 3.0 x16 |
| Slot 5 | PCI Express 3.0 x8 in a x16 size |
| Slot 6 | PCI Express 3.0 x8 in a x16 size |
Additional Information | |
| SLI Compatible | Yes |
| Crossfire Compatible | Yes |
| RAID Support | 0,1,5,10 |
BIOS Features | |
| UEFI BIOS | Yes |
| EZ Flash | Yes |
| OC Profiles | No |
Dimensions | |
| Height | 305 mm (12.0 in) |
| Width | 330 mm (13.0 in) |
*8 ports require the separate purchase of an ASUS PIKE SAS Controller
- Includes an Asus ASMB6-iKVM remote management module (included).
- RAID mode can be switched between either Intel RSTe (RAID 0,1,5,10) or LSI MegaRAID (RAID 0,1,10)
