Gigabyte B860I AORUS PRO ICE

Motherboard

Gigabyte B860I AORUS PRO ICE Main Picture


Gigabyte B860I AORUS PRO ICE Picture 88152Gigabyte B860I AORUS PRO ICE Picture 88153
The GIGABYTE B860I AORUS PRO ICE is a compact, ITX motherboard for Intel's Core Ultra Series 2 processors. This board's small footprint means it has very little internal expansion capability, but it does have a full PCI-Express 5.0 x16 slot for a video card and two DDR5 DIMM slots for up to 96GB of total system memory. Two M.2 drives are supported, along with two SATA ports and a few headers for chassis USB ports.

For external connectivity, the rear I/O panel has one Thunderbolt 4 port along with five USB 3.2 Type A ports of varying speeds. 2.5Gbps Ethernet and WiFi 7 are available for networking, along with HDMI and DisplayPort for output from the CPU's Intel graphics. Analog and digital audio connectors are both present as well, along with an antenna for the WiFi and Bluetooth 5.4.

Model: Gigabyte B860I AORUS PRO ICE

Specifications

Socket 1851
CPU Compatibility Intel Core Ultra Series 2
Form Factor Mini-ITX
Chipset Manufacturer Intel
Chipset B860
Network Connectivity 2.5G Networking + WiFi 7
Network Controller Realtek 2.5GbE LAN, MediaTek Wi-Fi 7 MT7925
Audio Controller Onboard Realtek HD Audio
Cooling System Passive Heatsink
Color White
Memory Support
Type DDR5
Maximum Speed 6400 MHz
Number of Slots 2
Maximum Size per Slot 64 GB
Maximum Amount Supported 128 GB
Onboard Video
Chipset Manufacturer Intel
Processor Type Processor Dependent
Maximum Resolution 5120x2880
Maximum HDMI Resolution  4096x2160
Maximum DisplayPort Resolution  3840x2160
HDMI 1
HDMI Version 2.1
DisplayPort 1
DisplayPort Version 2.1
Thunderbolt 1
Notes: 1x Thunderbolt 4 Type-C
External Connections
USB 3.2 Gen 1 (USB 3.0) 2
USB 3.2 Gen 2 (USB 3.1) 3
Audio Out Stereo
Audio In Line-In/Microphone
S/PDIF Optical
LAN (RJ45) 1
Wireless Antenna Port Yes
Thunderbolt Ports 1
Thunderbolt Version 4
BIOS Flashback Yes
Internal Connections
USB 2.0 1 (providing 2 ports)
USB 3.2 Gen 1 (USB 3.0) 1
USB 3.2 Gen 2 Type C 1
SATA III 6.0Gbps 2
M.2 Connector 2
M.2 Support 1x 80mm (PCIe 5.0), 1x 80mm (PCIe 4.0)
Expansion Slots
Slot 1 PCI Express 5.0 x16
Additional Information
Bluetooth Yes (5.4)
Integrated IO Shield Yes
BIOS Features
UEFI BIOS Yes
EZ Flash Yes
OC Profiles Yes
Dimensions
Height 170 mm (6.7 in)
Width 170 mm (6.7 in)
Net Weight 0.822 kg (1.8 lbs)
