Puget T460i 14 inch Notebook w/ Intel i7-4500U

Motherboard

Puget T460i 14 inch Notebook w/ Intel i7-4500U Picture 26603Puget T460i 14 inch Notebook w/ Intel i7-4500U Picture 26358Puget T460i 14 inch Notebook w/ Intel i7-4500U Picture 26359Puget T460i 14 inch Notebook w/ Intel i7-4500U Picture 26391Puget T460i 14 inch Notebook w/ Intel i7-4500U Picture 26361Puget T460i 14 inch Notebook w/ Intel i7-4500U Picture 26362
Model: Clevo W840SU-T w/ Intel i7-4500U

Specifications:
spacer
CPU Compatibility  Integrated Intel Core i7-4500U 1.8 GHz (3.0 GHz Turbo) Dual Core 4MB 15W
Form Factor  Notebook
Chipset Manufacturer  Intel
Chipset  HM87
Network Connectivity  Gigabit Networking
Cooling System  Heatsink and Fan
Number of Fans  1
Color  Black
Notebook-Display
Screen Size  14 Inch
Widescreen  Yes
Native Resolution  Full HD (1920x1080)
Surface  Glossy Finish Touch Display with 10-Point Multitouch
Memory Support
Type  DDR3 SODIMM
Maximum Speed  1600 MHz
Number of Slots  2
Maximum Size per Slot  8 GB
Maximum Amount Supported  16 GB
Onboard Video
Chipset Manufacturer  Intel
Processor Type  Integrated Intel HD 4400
HDMI  1
HDMI Version  1.4a
External Connections
USB 3.2 Gen 1 (USB 3.0)  2
Audio Out  Stereo
Audio In  Line-In/Microphone
LAN (RJ45)  1
Memory Card Reader  MMC/RSMMC/SD/Mini-SD/SDHC/SDXC
Fingerprint Reader  No
Internal Connections
SATA III 6.0Gbps  1
mSATA III 6.0Gbps  1
SATA Controllers
SATA III 6.0Gbps Controller 1  Intel HM87
mSATA III 6.0Gbps Controller 1  Intel HM87
Additional Information
Built-in Webcam  1Mpx
Built-in Microphone  Yes
BIOS Features
UEFI BIOS  Yes
EZ Flash  No
OC Profiles  No
Puget Measured Battery Life
Idle (Screen On)  537 Minutes
Movie Playback  306 Minutes
3D Graphics  202 Minutes
Dimensions
Height  22.9 mm (0.9 in)
Width  340 mm (13.4 in)
Depth  241 mm (9.5 in)
Net Weight  2 kg (4.4 lbs)
AC Adapter Input
Voltage  100~240 Vac
Frequency  50~60 Hz
AC Adapter Output
DC Voltage  19 V
Amperage  3.42 A

-Wireless and Bluetooth are purchased separately (unit only has 2 wifi antenna, and as such is not compatible with all WiFi cards)
-Accepts 2.5inch drives that are 7mm in height
