Shuttle SB75G2 Base System

Motherboard

Shuttle SB75G2 Base System Main Picture


Shuttle SB75G2 Base System Picture 3327Shuttle SB75G2 Base System Picture 3328Shuttle SB75G2 Base System Picture 3329Shuttle SB75G2 Base System Picture 3330Shuttle SB75G2 Base System Picture 3334

Specifications

Form Factor Shuttle/Socket 478
Chipset Intel 875P/ICH5-R

Memory Type: DDR333/400
Max CPU: 3200
Max Memory: 2 GB
Memory Slots: 2
AGP: 8x
# PCI: 1
Onboard Items: Audio/Gb LAN/USB/1394
Hard Drive Support: 2xUDMA100

Compact, sturdy aluminum case.

Dimensions: 300 (L) x 200 (W) x 185 (H)
Weight: 2.4Kg (N.W), 3.55Kg (G.W)
