Model: Supermicro X7DB8
CPU: Dual 771-pin LGA Sockets Supports Intel 64-bit Dual-Core Xeon Processor 5000 sequence; FSB 1333/1066/667 MHz
Chipset: Intel 5000P (Blackford) chipset & MCH + PXH + ESB2
Memory: 8x 240pin DIMMs support Dual Branch Memory Bus, DDR2 667/533 ECC FB-DIMM memory; Max capacity 32GB
Slots: 2x PCI Express x8 slots; 1x PCI Express x4 slot (Run on x8); 1x SEPC (Supermicro PCI-e Power Connector) slot for 2U active riser cards with a power extension; 2x 64-bit 133MHz PCI-X (3.3V) slots; 1x 64-bit 100MHz PCI-X (3.3V) slot
IDE/SATA: 1x ATA-100 channel; 6x SATA ports
SCSI: Adaptec AIC-7902 Controller Dual-Channel Ultra320 SCSI (Host RAID only supports 4 drives) support RAID 0, 1, & 10
Video: ATI ES1000 controller with 16 MB of video memory
LAN: Intel (ESB2/Gilgal) 82563EB Dual-Port Gigabit Ethernet Controller
Ports: 5x USB 2.0/1.1 ports (2 rear, 3 header); 2x RJ45; 1x VGA port; 2x PS/2 ports; 1x serial port; 1x parallel port
Form Factor: Extended ATX, 12 x 13.05 inch / 30.5 x 33.2 cm
Package: Retail
To ensure system stability, a 500W (minimum) ATX power supply are required.
RoHS compliant
