GPU: RADEON™ 9600PRO
Memory: 128MB DDR MB
Interface: AGP 1X/2X/4X/8X
Clock Speed: 400MHz
Memory Speed: 650MHz
"Connectors:
x FM Radio Antenna connection
1 x Cable TV/Antenna connectionrn 1 x S-Video Inrn 1 x New Video Out
Max Resolution:
048X1536@60Hz
3D Acceleration Features:
MARTSHADER 2.1rn Full support for Microsoft DirectX 9.0 programmable pixel and
vertex shaders in hardware
2.0 Pixel Shaders support up to 16 textures per rendering pass
2.0 Vertex Shaders support vertex programs up to 1024 instructions with
flow control
New 128-bit per pixel floating point color formats
Multiple Render Target (MRT) support
Shadow volume rendering acceleration
Complete feature set also supported in OpenGL via extensions
SMOOTHVISION 2.1rn State-of-the-art full-scene anti-aliasing
New technology processes up to 15.6 billion anti-aliased samples per
second for unprecedented performance
Supports 2x, 4x, and 6x modes with programmable sample patterns
Advanced anisotropic filtering
Supports up to 16 bilinear samples (in performance mode) or trilinear
samples (in quality mode) per pixel
2x/4x/6x full scene anti-aliasing modes
Adaptive algorithm with programmable sample patterns
2x/4x/8x/16x anisotropic filtering modes
Adaptive algorithm with bilinear (performance) and trilinear (quality)
options Bandwidth-saving algorithm enables this feature with minimal performance
cost HYPERZ III+Hierarchical Z-Buffer and Early Z Test reduce overdraw by detecting and
discarding hidden pixels Lossless Z-Buffer Compression and Fast Z-Buffer Clear reduce memory bandwidth
consumption by over 50% Fast Z-Buffer Clear DISPLAY SUPPORTrn 15-pin VGA connector for analog CRT / DVI-I connector for digital CRT
or flat panel
S-video or composite connector for TV/VCRIndependent resolutions and refresh rates for any two connected displays
GENERAL FEATURESComprehensive 2x, 4x, and 8x AGP support
DDR memory interface supports 64/128/256MB configurationsrn Fully compliant with PC 2002 requirements
Optimized for Pentium 4 SSE2 and AMD Athlon 3Dnow! processor
instructions Supports optional THEATER 200 companion chip for NTSC/PAL/SECAM
video captureHighly optimized 128-bit 2D engine with support for new Windows
XP GDI extensions"
