Asus GeForce RTX 3070 Turbo 8GB Blower

Video Card

[ Rear Ports ]

Asus GeForce RTX 3070 Turbo 8GB Blower Picture 67090Asus GeForce RTX 3070 Turbo 8GB Blower Picture 67091Asus GeForce RTX 3070 Turbo 8GB Blower Picture 67092Asus GeForce RTX 3070 Turbo 8GB Blower Picture 67093Asus GeForce RTX 3070 Turbo 8GB Blower Picture 67094Asus GeForce RTX 3070 Turbo 8GB Blower Picture 67095
NVIDIA's GeForce RTX 3070 is their third consumer graphics card based on the Ampere architecture, which in turn is the second generation of NVIDIA GPUs to offer hardware raytracing and other advanced features under their RTX branding. The performance increase this video card brings varies depending on workflow, with the biggest improvements coming in areas like 3D rendering, video editing, and game engines. In general, though, it should match or beat the performance of the older RTX 2080 Ti card in most applications.

This variant from Asus uses a single-fan, blower-style cooler. That means most of the heat generated by the card is exhausted out the back of the system, making this design ideal for multi-GPU configurations. In trade it will make a lot more noise under load, since the one fan has to run at much higher RPMs in order to dissipate the same amount of heat as the two or three fans on other variants.

Finally, in regards to connectivity, this card has one HDMI 2.1 and three DisplayPort 1.4a plugs supporting a total of up to four displays at a maximum resolution of 7680x4320 (8K).
Model: Asus TURBO-RTX3070-8G

Chipset Manufacturer  NVIDIA
Product Line  GeForce
Series  RTX 3000
Model  3070
Motherboard Connection  PCI Express 4.0 x16
Maximum Digital Resolution  7680x4320
Maximum HDMI Resolution  7680x4320
Maximum DisplayPort Resolution  7680x4320
Maximum Monitors Supported  4
HDCP Compliant  Yes
Multi-GPU Technology  Not Available
Lite Hash Rate  No
GPU Specifications
Core Speed  1,500 MHz
Boost Speed  1,725 Mhz
Stream Processors  5888
Memory Specifications
Video Memory  8GB
Memory Type  GDDR6
Memory Speed  14,000 MHz
Memory Bus Width  256-bit
Bandwidth  448 GB/s
Additional Information
Cooling System  Blower Type
DirectX Support  DirectX 12
CUDA Support  11
OpenGL Support  4.5
Removable Backplate  No
Slot Width  2
Port 1  HDMI
Port 2  DisplayPort
Port 3  DisplayPort
Port 4  DisplayPort
Power Connectors
Plug 1  8-pin PCI-E
Plug 2  8-pin PCI-E
Length  269 mm (10.6 in)
Height  112 mm (4.4 in)
Width  40 mm (1.6 in)
Net Weight  1.1 kg (2.4 lbs)

Configure a custom computer with the Asus GeForce RTX 3070 Turbo 8GB Blower.
