Model: Pinnacle 210100427
Features
- PLUS : Multi-track video editing
- PLUS : Chroma Key (Blue screen) effects
- PLUS : Picture-in-Picture (PIP) effects
- PLUS : Animated photo slide shows with Pan-and-Zoom effects
- Capture and edit wide-screen (16:9) or standard (4:3) video
- Capture and edit footage from your DV, Digital8 or MicroMV digital camcorder
- Capture and edit footage from your 8mm, VHS, SVHS, VHS-C, or SVHS-C analog camcorder
- Capture and edit DVD quality MPEG video from your DV or Digital8 camcorder
- Import and edit MPEG-1 and MPEG-2 files
- Easy drag-and-drop editing lets you assemble your masterpiece
- Advanced timeline features for frame-by-frame editing
- Preview window shows your edits immediately
- More than 100 scene transitions and Hollywood FX 3D transitions
- Professional title effects with Pinnacle TitleDeko, including drop shadows and neon glows
- Fast/slow motion effects
- Special video effects and image correction
- Video enhancement
- Image stabilization
- Automatic colour correction
- Analog cleaner
- Support for RTFx plug-ins
- Effect fade in fade out
- Import background music as MP3 files or rip directly from an audio CD
- Record your own voice-over narration
- Create custom musical soundtracks precisely matched to the duration of your movie
- Audio noise removal
- Stereo panning
- Surround sound pan
- Graphic EQ
- Support for VST audio effect plug-ins
- Professional plug-in for Pinnacle Studio
- 288 Unique 2D 3D transitions and video effects
- Customizable, with included editor
- Share your movies on video tape, DVD, Video CD, and the Internet
- Burn a video CD or DVD that you can play on your living room DVD player
- Supports single and dual-layer DVD burning
- Output MPEG-1, MPEG-2 MPEG-4
- Output Dolby Digital Audio
- Output wide-screen (16:9) or standard (4:3) video
- Output Windows Media 9
System Requirements
Processor: Intel Pentium or AMD Athlon 800 MHz or higher (1.5 GHz or higher recommended)
Memory: 256 MB RAM (512 MB recommended)
Operating System: Windows 98SE, #34;Millennium#34;, 2000, XP (Windows XP recommended. MicroMV support and dual layer DVD burning require Windows XP)
Graphics: DirectX 9 or higher compatible graphics card (ATI Radeon or NVIDIA GeForce 2 or higher recommended)
Sound: DirectX 9 or higher compatible sound card
Disk Storage: 500 MB of disk space to install software
Other: CD-ROM drive
Optional: 16
Hardware specifications
Plug and Play: 32 bit PCI board with bus mastering interface
Video Inputs
Composite video input: (RCA connector) NTSC
S-Video input: (mini-DIN connector) NTSC
Stereo audio input: (2 x RCA connectors)
IEEE1394 I/O connector (6-pin type): I/O connector (6-pin type)
Video Capture to Computer
Analog NTSC: input 720x480, 30 fps
DV (IEEE1394) camcorder capture 25Mbit/s: Full camera control support
Compresion: MPEG-1, MPEG-2, DV, MJPEG (User selectable. Available real-time capture formats depend on CPU speed)
Video Playback from Computer
Analog NTSC output: 720x480, 30fps
DV (IEEE1394) output: to camcorder 25Mbit/s. Full camera/device control support
Software Specifications
Input Formats: 120 MB of disk space for every 20 minutes of DV video captured at preview quality (4 GB for every 20 minutes of finished movie)
Output Formats: MPEG-1, MPEG-2 MPEG-4 . AVI . RealVideo 8 . Windows Media 9 . Dolby Digital Audio
Import
Video: MPEG-1, MPEG-2, AVI
Audio: WAV, MP3
Graphic: BMP, JPG, PCT, TGA, TIF, WMF
Studio AV/DV Deluxe is the ultimate internal video editing solution. Capture and edit home movies on your PC using any consumer videotape format. The package includes; a professional breakout box for easily attaching analog or digital video sources, Pinnacle Studio PLUS v.9--the advanced version of Studio v.9 that offers more powerful and creative capabilities while retaining the award-winning interface and workflow--and Pinnacle Hollywood FX Plus, which provides hundreds of additional 2D and 3D transitions and video effects.
Connect Any Camcorder Or VCR To Your PC
DV, D8, VHS, Hi-8 Video can be captured from both analog and digital tapes, and mixed into your production. Once your project is complete, you can then output it to either digital or analog tape.
Digitise Almost Any Analog Video
With the Studio AV/DV Deluxe you can connect any analog video device: camcorder, VCR, DVD player, TV, etc. Pinnacle Studio software is the perfect tool to restore and preserve your video collection on CDs and DVDs.
Unique Custom Chip For Highest Quality Video
The heart of Pinnacle Studio AV/DV Deluxe video capture board is a proprietary custom integrated circuit developed by Pinnacle using its years of experience providing professional video solutions to the TV Broadcasting Industry.
