Intel Core i7 9800X 3.8GHz Eight Core 16.5MB 165W

CPU

Intel Core i7 9800X 3.8GHz Eight Core 16.5MB 165W Picture 51267

Background on Intel Core X-series CPU

Intel's enthusiast-class "Core X" processors represent the top-end of their consumer CPU line, and bridge the gap between the more mainstream chips and the Xeon server-grade models. The current 9000-series processors in this line range from eight to eighteen cores, with base clock speeds of 3.0 to 3.8GHz - and turbo boost speeds of up to 4.4GHz. The combination of high core counts with high clock frequencies allow these processors to excel at both single and multi-threaded workloads, while supporting more RAM and PCI-E lanes than the less expensive Core series.

William George (Puget Labs Technician)
William George (Puget Labs Technician) Says:
These processors were codenamed Skylake-X, when first announced, but Intel seems to have standardized on calling them Core X processors. There were also some Kaby Lake-X chips that share the same socket and were compatible with some of the same motherboards, but they had fewer memory channels and PCI-E lanes, so to avoid confusion and situations where lots of motherboard features are disabled we chose not to offer them.

Model: Intel CD8067304126100

Specifications:
spacer
Product Line  Core i7
Code Name  Skylake-X
Socket  2066
Process  14 nm
Number of Cores  8
Clock Speed  3.80 GHz
Hyperthreading  Yes
Turbo Boost  Yes
Max. Turbo Boost  4.50 GHz
All-Core Turbo Boost  4.10 GHz
Bus Type  DMI3
Thermal Output  165 W
PCI-E Lanes  44
Cache
Smart Cache  16.5MB
Memory Specification
Memory Type  DDR4
Maximum Frequency  2666
ECC Support  No
Advanced Technologies
vPro  Yes
Virtualization Technology (VT-x)  Yes
Virtualization Technology for Directed I/O (VT-d)  Yes
Trusted Execution Technology  Yes
TSX-NI  Yes

Warranty:

1 Year




Configure a gaming PC with the Intel Core i7 9800X 3.8GHz Eight Core 16.5MB 165W.
