Intel Core i9 10940X 3.3GHz 14 Core 19.25MB 165W
CPU
Background on Intel Core X-series CPU
Intel's enthusiast-class "Core X" processors represent the top-end of their consumer CPU line, and bridge the gap between the more mainstream chips and the Xeon server-grade models. The current processors in this line range from ten to eighteen cores, with base clock speeds of 3.0 to 3.7GHz - and turbo boost speeds of up to 4.8GHz. The combination of high core counts with high clock frequencies allow these processors to excel at both single and multi-threaded workloads, while supporting more RAM and PCI-E lanes than the less expensive Core series.
William George (Product Development) Says:
Multiple generations of processors from Intel have now carried the "Core X" moniker, which can make this product line a little confusing. Some previous generations have included models with limited numbers of PCI-E lanes or reduced RAM capacity, but the latest 10000-series seems to have done away with that. Intel also drastically cut the price on this processor family, which is great!
Multiple generations of processors from Intel have now carried the "Core X" moniker, which can make this product line a little confusing. Some previous generations have included models with limited numbers of PCI-E lanes or reduced RAM capacity, but the latest 10000-series seems to have done away with that. Intel also drastically cut the price on this processor family, which is great!
Model: Intel i9-10940X
Specifications:
Specifications:
| Product Line | Core i9 |
| Code Name | Cascade Lake-X |
| Socket | 2066 |
| Process | 14 nm |
| Total Number of Cores | 14 |
| Base Clock Speed | 3.30 GHz |
| Hyperthreading | Yes |
| Turbo Boost | Yes |
| Max. Turbo Boost | 4.60 GHz |
| Intel Turbo Boost Max 3.0 | 4.80 GHz |
| All-Core Turbo Boost | 4.10 GHz |
| Bus Type | DMI3 |
| Thermal Output | 165 W |
| PCI-E Lanes | 48 |
| Max Temperature | 86 C |
| Cache | |
| Smart Cache | 19.25MB |
| Memory Specification | |
| Memory Type | DDR4 |
| Maximum Frequency | 2933 |
| ECC Support | No |
| Registered Support | No |
| Advanced Technologies | |
| vPro | Yes |
| Virtualization Technology (VT-x) | Yes |
| Virtualization Technology for Directed I/O (VT-d) | Yes |
| Trusted Execution Technology | Yes |
| TSX-NI | Yes |
Max memory speed is reduced to 2666MHz when configured with two DIMMs per channel.
Configure a custom computer with the Intel Core i9 10940X 3.3GHz 14 Core 19.25MB 165W.
