Intel Core i9 9940X 3.3GHz Fourteen Core 19.25MB 165W

CPU

Intel Core i9 9940X 3.3GHz Fourteen Core 19.25MB 165W Picture 51272

Background on Intel Core X-series CPU

Intel's enthusiast-class "Core X" processors represent the top-end of their consumer CPU line, and bridge the gap between the more mainstream chips and the Xeon server-grade models. The current 9000-series processors in this line range from eight to eighteen cores, with base clock speeds of 3.0 to 3.8GHz - and turbo boost speeds of up to 4.4GHz. The combination of high core counts with high clock frequencies allow these processors to excel at both single and multi-threaded workloads, while supporting more RAM and PCI-E lanes than the less expensive Core series.

William George (Puget Labs Technician)
William George (Puget Labs Technician) Says:
These processors were codenamed Skylake-X, when first announced, but Intel seems to have standardized on calling them Core X processors. There were also some Kaby Lake-X chips that share the same socket and were compatible with some of the same motherboards, but they had fewer memory channels and PCI-E lanes, so to avoid confusion and situations where lots of motherboard features are disabled we chose not to offer them.

Model: Intel CD8067304175600

Specifications:
spacer
Product Line  Core i9
Code Name  Basin Falls
Socket  2066
Process  14 nm
Number of Cores  14
Clock Speed  3.30 GHz
Hyperthreading  Yes
Turbo Boost  Yes
Max. Turbo Boost  4.50 GHz
All-Core Turbo Boost  4.10 GHz
Bus Type  DMI3
Thermal Output  165 W
PCI-E Lanes  44
Cache
Smart Cache  19.25MB
Memory Specification
Memory Type  DDR4
Maximum Frequency  2666
ECC Support  No
Advanced Technologies
vPro  Yes
Virtualization Technology (VT-x)  Yes
Virtualization Technology for Directed I/O (VT-d)  Yes
Trusted Execution Technology  Yes
TSX-NI  Yes

Warranty:

1 Year




Configure a custom workstation with the Intel Core i9 9940X 3.3GHz Fourteen Core 19.25MB 165W.
