Intel Xeon E5-1620 V4 3.5GHz 4 Core 10MB 140W


Intel Xeon E5-1620 V4 3.5GHz 4 Core 10MB 140W Picture 39726

Background on Intel Xeon E5 1600 V4 CPU

Intel's E5 1600 V4 series of Xeon processors are based on the Broadwell EP architecture, and the updated socket 2011-3 for mounting. This brings technology improvements from the enthusiast Broadwell-E series into the server and workstation areas, along with support for features like ECC memory.

For the most part, this generation duplicates the speed and core count options available on the equivalent Core i7 enthusiast line. Not every model lines up with a Core i7 exactly, though: in particular there are some quad-core options which have no match on the i7 side.

William George (Puget Labs)
William George (Puget Labs) Says:
Most of the processors in this line are effectively just Xeon variants of the Core i7 Broadwell E processor line. The same combinations of cores and clock speed are available, with one higher-speed 8-core model and some quad-core variants added as well. If you need even higher core counts, the Xeon E5 2600 v3 & v4 series can also be used in single-CPU configurations and offer a wider range of specs.

Model: Intel BX80660E51620V4

Product Line  Xeon
Code Name  Broadwell-EP
Socket  2011-3
Process  14 nm
Number of Cores  4
Clock Speed  3.5 GHz
Hyperthreading  Yes
Turbo Boost  Yes
Max. Turbo Boost  3.8 GHz
All-Core Turbo Boost  3.6 GHz
Bus Type  DMI2
Thermal Output  140 W
PCI-E Lanes  40
Smart Cache  10MB
Memory Specification
Memory Type  DDR4
Maximum Frequency  2400
ECC Support  Yes
Advanced Technologies
vPro  Yes
Virtualization Technology (VT-x)  Yes
Virtualization Technology for Directed I/O (VT-d)  Yes
Trusted Execution Technology  Yes

Configure a scientific workstation with the Intel Xeon E5-1620 V4 3.5GHz 4 Core 10MB 140W.
