Intel Xeon E5-2690 V3 2.6GHz Twelve Core 30MB 135W

CPU

Intel Xeon E5-2690 V3 2.6GHz Twelve Core 30MB 135W Picture 32656
Model: Intel CM8064401439416

Specifications:
spacer
Product Line  Xeon
Code Name  Haswell-EP
Socket  2011-3
Process  22 nm
Number of Cores  12
Clock Speed  2.6 GHz
Hyperthreading  Yes
Turbo Boost  Yes
Max. Turbo Boost  3.5 GHz
All-Core Turbo Boost  3.1 GHz
Bus Type  DMI2
QPI Speed  9.6 GT/s
Thermal Output  135 W
PCI-E Lanes  40
Cache
Smart Cache  30MB
Memory Specification
Memory Type  DDR4
Maximum Frequency  2133
ECC Support  Yes
Advanced Technologies
vPro  Yes
Virtualization Technology (VT-x)  Yes
Virtualization Technology for Directed I/O (VT-d)  Yes
Trusted Execution Technology  Yes

-More information on the operating frequency this CPU is capable of with different numbers of active cores is available on page 8, table 2 of Intel's Xeon E5 V3 Spec Update datasheet.
-Turbo Boost frequencies for AVX are generally .1GHz lower than the standard Turbo Boost frequencies. See above datasheet (page 10) for exact frequencies.
