Background on Intel Xeon E7 v4 CPU
Intel's E7 v4 series of Xeon processors are based on the Broadwell EX architecture, and utilize the same socket 2011 for mounting. These are the top-end of the modern Xeon line in terms of the number of supported CPUs in a single system, allowing for 4-way or 8-way operation... though the motherboard we use here at Puget is limited to 4 physical CPUs. Still, that allows for up to 96 actual processing cores - or 192 threads, thanks to Intel's Hyperthreading technology.
Quad-channel DDR4 memory per CPU is supported, just as with the dual processor Xeons, allowing for massive amounts of RAM and high memory bandwidth to keep all those cores fed with data. The size of motherboard required to fit four sockets and the accompanying RAM slots means that only the largest cases can fit a system built on this architecture.
Please note that due to the rarity of these processors, some will require an additional 4 to 6 week lead time for orders using them. Please work with one of our consultants if you need assistance or have any questions!
|Number of Cores||10|
|Clock Speed||2.0 GHz|
|Max. Turbo Boost||2.8 GHz|
|All-Core Turbo Boost||2.2 GHz|
|Bus Type||QuickPath Interconnect|
|QPI Speed||6.4 GT/s|
|Thermal Output||115 W|
|Virtualization Technology (VT-x)||Yes|
|Virtualization Technology for Directed I/O (VT-d)||Yes|
|Trusted Execution Technology||Yes|
- Intel Xeon E7-4830 V4 2.0GHz Fourteen Core 35MB 115W Utility
- WEI Hotfix
- WEI Hotfix
Configure a custom computer with the Intel Xeon E7-4830 V4 2.0GHz Fourteen Core 35MB 115W.
