Intel Xeon W-2195 2.3GHz 18 Core 24.75MB 140W


Intel Xeon W-2195 2.3GHz 18 Core 24.75MB 140W Picture 45966

Background on Intel Xeon W-2100 Series

Intel's Xeon W series of processors are based on the Skylake W architecture, which is similar to Skylake X but has been adapted for workstation and server use. To that end, these CPUs have support for Registered ECC memory, higher RAM capacities, and a slightly increased PCI-E lane count compared to the enthusiast Core X series. The same socket 2066 is used, but in order to properly support the added feature set a different chipset / motherboard is required for the Xeon W processors.

Model: Intel CD8067303805901

Product Line  Xeon
Code Name  Skylake
Socket  2066
Process  14 nm
Number of Cores  18
Clock Speed  2.30 GHz
Hyperthreading  Yes
Turbo Boost  Yes
Max. Turbo Boost  4.30 GHz
All-Core Turbo Boost  3.20 GHz
Bus Type  DMI3
Thermal Output  140 W
PCI-E Lanes  48
Smart Cache  24.75MB
Memory Specification
Memory Type  DDR4
Maximum Frequency  2666
ECC Support  Yes
Advanced Technologies
vPro  Yes
Virtualization Technology (VT-x)  Yes
Virtualization Technology for Directed I/O (VT-d)  Yes
Trusted Execution Technology  Yes


1 Year

Configure a scientific workstation with the Intel Xeon W-2195 2.3GHz 18 Core 24.75MB 140W.
