Intel Xeon W-3265 2.7GHz Twenty-Four Core 33MB 205W


Intel Xeon W-3265 2.7GHz Twenty-Four Core 33MB 205W Picture 56335

Background on Intel Xeon W-3200 Series

Intel's Xeon W-3200 series is based on the Cascade Lake Xeon Scalable architecture. This brings a higher core count, more memory channels, and support for more PCI-Express lanes to a single-socket workstation platform than Intel has previously offered. That combination makes these Xeon W chips a great choice for high performance workstations, especially when multiple GPUs are needed, but it comes with a higher price tag than other workstation-focused Xeons as well.

Model: Intel CD8069504153002

Product Line  Xeon W
Code Name  Cascade Lake-64L
Socket  3647
Process  14 nm
Total Number of Cores  24
Base Clock Speed  2.70 GHz
Hyperthreading  Yes
Turbo Boost  Yes
Max. Turbo Boost  4.40 GHz
Intel Turbo Boost Max 3.0  4.60 GHz
All-Core Turbo Boost  3.40 GHz
Bus Type  DMI3
Thermal Output  205 W
PCI-E Lanes  64
Max Temperature  85 C
Smart Cache  33MB
Memory Specification
Memory Type  DDR4
Maximum Frequency  2933
ECC Support  Yes
Registered Support  Yes
Advanced Technologies
vPro  Yes
Virtualization Technology (VT-x)  Yes
Virtualization Technology for Directed I/O (VT-d)  Yes
Trusted Execution Technology  Yes

Max memory speed is reduced to 2666MHz when configured with two DIMMs per channel.

Configure a custom computer with the Intel Xeon W-3265 2.7GHz Twenty-Four Core 33MB 205W.
