Intel Xeon w5-3425 3.2GHz 12 Core 30MB 270W

CPU

Intel Xeon w5-3425 3.2GHz 12 Core 30MB 270W Main Picture


Background on Intel Xeon W-3400 Series

Intel's Xeon W-3400 series is their top-end, single-socket processor line. Designed for heavily threaded and memory-intensive applications, these CPUs support eight-channel DDR5 memory, 112 PCI-Express lanes, and up to 56 CPU cores. This represents a substantial core count increase from the previous W-3300 series and lower-cost W-2400, along with double the memory bandwidth and PCIe lanes compared to that lineup.


Model: Intel PK8071305082100

Specifications

Product Line Xeon W
Code Name Sapphire Rapids
Socket 4677
Process 10 nm
Total Number of Cores 12
Base Clock Speed 3.20 GHz
Hyperthreading Yes
Turbo Boost Yes
Max. Turbo Boost 4.60 GHz
Intel Turbo Boost Max 3.0 4.60 GHz
Long Duration Power Limit 270 W
Short Duration Power Limit 324 W
PCI-E Lanes 128
Bus Type DMI4
Max Temperature 100 C
Cache
Smart Cache 30MB
Memory Specification
Memory Type DDR5
Maximum Frequency 4800
ECC Support Yes
Registered Support Yes
Advanced Technologies
vPro Yes
Virtualization Technology (VT-x) Yes
Virtualization Technology for Directed I/O (VT-d) Yes
Trusted Execution Technology Yes
