EVGA GeForce GTX 1080 Ti 11GB

Video Card

EVGA GeForce GTX 1080 Ti 11GB Main Picture


EVGA GeForce GTX 1080 Ti 11GB Picture 42079
NVIDIA's GeForce GTX 1080 Ti represents a refresh to their new Pascal graphics card line. It improves upon the original GTX 1080 with both more graphics processors (CUDA cores) and additional video RAM. Those combine to provide a substantial boost in performance, with the GTX 1080 Ti about 30% faster than the GTX 1080 - and even a hair faster than the Titan X, though without quite as much onboard memory as that model.

In addition to its great speed and efficiency, the GTX 1080 Ti shares the under-the-hood improvements that all Pascal cards have for boosting virtual reality and multi-monitor performance. It is excellent at maintaining good frame-rates in games and VR experiences, even in graphics-laden titles and at high resolutions, and includes support for CUDA, DX12, and NVIDIA's 3D Vision technology. Finally, it supports up to 4 usable display outputs: one HDMI 2.0 and three DisplayPorts. The older DVI connection has been removed, which allows more room for the card to vent hot air.
William George (Marketing Project Manager)
William George (Marketing Project Manager) Says:
The GTX 1080 Ti is the fastest video card for gaming, as of its launch in March 2017, and it should excel in other GPU accelerated applications as well. It is probably overkill for gaming at anything below 4K 60Hz or 1440P 120Hz, but if you want the best then this is it (until the next generation of GeForce cards come out, at least). It should also do very well in scientific computing with single precision (FP32) calculations.

Model: EVGA 11G-P4-6390-KR

Specifications

Chipset Manufacturer NVIDIA
Product Line GeForce
Interface PCI Express 3.0 x16
Maximum Digital Resolution 7680x4320
Maximum Monitors Supported 4
HDCP Compliant Yes
GPU Specifications
Core Speed 1480 MHz
Boost Speed 1582 Mhz
Stream Processors 3584
Memory Specifications
Video Memory 11GB
Memory Type GDDR5X
Memory Speed 11000 MHz
Memory Bus Width 352-bit
Bandwidth 484 GB/s
Additional Information
Cooling System Blower Type
DirectX Support DirectX 12
CUDA Support 6.1
OpenGL Support 4.5
Outputs
Port 1 HDMI
Port 2 DisplayPort
Port 3 DisplayPort
Port 4 DisplayPort
Power Connectors
Plug 1 6-pin PCI-E
Plug 2 8-pin PCI-E
Dimensions
Length 266.7 mm (10.5 in)
Height 111.2 mm (4.4 in)
Width 38.1 mm (1.5 in)
