Haswell Core i3 vs. i5 vs. i7 - Which is right for you?

Written on June 2, 2013 by Matt Bach
Share:

Introduction

Intel has been using the i3, i5, and i7 naming scheme for their CPUs for quite a while now, but what these labels mean tends to slowly change over time as new features are introduced or older ones get replaced. On top of this, the naming scheme between desktop and mobile CPUs is often different as well. In this article, we will go over what differentiates i3, i5, and i7 processors for both mobile and desktop Haswell CPUs.

The biggest thing you need to know in regards to the i3, i5, and i7 naming scheme is that it is primarily a way for Intel to separate their CPUs into three performance tiers:

Intel Core i7: High-end
Intel Core i5: Mainstream
Intel Core i3: Entry-level

There are a few differences in features (notably Hyperthreading, cache size, and number of cores), but as we will show later in this article there is actually very little that differentiates an i5 CPU from an i7 CPU. The biggest thing that this naming scheme gives you is a starting place when choosing a CPU. If you use your computer for basic tasks like surfing the web, then an i3 CPU is likely a great choice. If you use your computer for a variety of tasks that require a bit more power (including gaming), than an i5 CPU might be a better choice. If you run multiple applications that require a lot of CPU power, then an i7 CPU is probably right for you.

Desktop CPUs

  Frequency Turbo Boost Cores Hyperthreading Smart Cache TDW Graphics
Core i7 2.0-3.5GHz 4 8MB 35-84W Intel HD 4600
Core i5 3.0-3.4GHz 4 4-6MB 35-84W Intel HD 4600
Core i3 2.4-3.6GHz 2 3-4MB 35-54W Varies

Overall, the chart above can be summarized with the following:

  1. The CPU frequency and thermal output (TDW) is largely not determined by the Core i_ name
  2. Core i5 and i7 both have Turbo Boost while the i3 does not
  3. Core i5 and i7 CPUs have 4 cores, while i3 CPUs only have 2
  4. Core i5 CPUs lack Hyperthreading
  5. Core i7 CPUs have more Smart Cache than i5 CPUs, which in turn have more cache than i3 CPUs
  6. Core i5 and i7 CPUs have the same graphics, although the speed of that graphics will depend on the individual CPU. Core i3 CPUs have variable graphics depending on the price-point of the CPU.

So while i7 CPUs do have overall better specifications than i5 CPUs, there is actually quite a bit of overlap between the two except that i5 CPUs do not support Hyperthreading. Especially in terms of frequency and thermal output, the two lines really are not very different. For i3 CPUs, the main difference is that they only have two cores, a smaller cache, do not support Turbo Boost and have overall lower thermal output than i5 and i7 CPUs.

Mobile CPUs

  Frequency Turbo Boost Cores Hyperthreading Smart Cache TDW Graphics
Core i7 2.7-3.0 GHz 4 6-8MB 47-57W Intel HD 4600
Core i5
Unreleased
1.5-2.8 GHz 2 3MB 17-57W Intel HD 4600
Core i3
Unreleased
1.4-2.6 GHz 2 3MB 13-45W Intel HD 4600

Currently, there are no Haswell Core i3 or i5 mobile CPUs available for consumers. The values in the chart above are our prediction based on previous generations.

Overall, the chart above can be summarized with the following:

  1. There is a lot of overlap in CPU frequency and thermal output (TDW) between i3, i5 and i7 CPUs. Core i7 CPUs will have a slightly higher top-end frequency and wattage, while i3/i5 CPUs have lower bottom-end frequency and wattage.
  2. All Haswell mobile CPUs released so far have both Turbo Boost and Hyperthreading (although i3 is likey to not support Turbo Boost)
  3. Core i7 CPUs have 4 cores, while i5 and i3 CPUs (should) only have 2
  4. Core i7 CPUs have more Smart Cache than i5 and i3 CPUs
  5. All CPUs have the same graphics core (although i3 and i5 is unconfirmed), although the speed of that graphics will depend on the individual CPU

In this case, the main advantage of the Core i7 CPUs is that they have 4 cores, but at the same time they also have an overall higher thermal output. Core i5 and i3 CPUs are actually very similar to each other except that the i3 CPUs are likely to not support Turbo Boost and have slightly lower frequency and power draw than the i5 CPUs.

Conclusion

The main thing to remember is that i7 CPUs are at the high end of the product line, i5 CPUs are in the middle, and i3 CPUs are entry level. This gives you a decent starting place to look for a CPU based on what you will be using your computer for, but you will likely need to look at the individual specs for multiple CPUs to determine which is actually the right fit for you. While there are a few things that the i3/i5/i7 naming scheme tells you, it is really no substitution for actually looking at the specifications of individual CPUs. The Intel Ark is one way to do so, and it allows you to select multiple CPUs to compare side by side. Additionally, if you are in the market for a new computer based on these CPUs, our sales staff is always happy to answer questions at sales@pugetsystems.com.
