After Effects CPU performance: Intel Core 10th Gen vs AMD Ryzen 3rd Gen

Written on May 20, 2020 by Matt Bach
Share:

TL;DR: Intel Core 10th Gen vs AMD Ryzen 3rd Gen for After Effects

In Adobe After Effects, there isn't much of a difference in overall performance between the Intel 10th Gen and AMD Ryzen 3rd Gen processors. The AMD Ryzen 9 3900X and 3800X are about 5% faster than the Intel 10th Gen CPUs for tracking, which can make AMD a slightly better choice for some users depending on how much tracking they do in After Effects.

However, the Intel Core i9 10900K and Core i7 10700K are about 5% faster than their AMD Ryzen counterparts for RAM preview and rendering, which is going to make them slightly more attractive for most After Effects users.

Introduction

For a very long time, Intel processors have held our solid recommendation for After Effects since AE typically only uses a handful of cores and Intel tends to have higher per-core performance compared to AMD. However, with AMD's Ryzen 3rd Gen CPUs that were released in July of 2019, AMD was able to close the gap to the point that they only trailed behind the Intel 9th Gen CPUs by about 5% in After Effects. A 5% difference in performance is going to be hard to notice in the real world, which meant that (depending on what other applications you use in your workflow) there was an argument to be made for going with either brand.

With the launch of the new Intel 10th Gen desktop processors, we are interested to see if Intel is able to capture a solid lead once again in After Effects.

Intel Core 10th Gen vs AMD Ryzen 3rd Gen for Adobe After Effects

In this article, we will be examining the performance of the new Intel 10th Gen Core i9 10900K, i7 10700K, and i5 10600K in After Effects compared to a range of CPUs including the AMD Ryzen 3rd Gen, Intel X-10000 Series, AMD Threadripper 3rd Gen, as well as the previous generation Intel 9th Gen processors. In addition, we will be including a 2019 Mac Pro and iMac Pro to act as additional reference points. If you are interested in how these processors compare in other applications, we also have other articles for Premiere Pro, Photoshop, Lightroom Classic, and several other applications available on our article listing page.

If you would like to skip over our test setup and benchmark sections, feel free to jump right to the Conclusion.

Looking for an After Effects Workstation?

Puget Systems offers a range of powerful and reliable systems that are tailor-made for your unique workflow.

Configure a System!

Labs Consultation Service

Our Labs team is available to provide in-depth hardware recommendations based on your workflow.

Find Out More!

Test Setup

Listed below are the specifications of the systems we will be using for our testing:

Intel 10th Gen Test Platform
CPU Intel Core i9 10900K ($488)
Intel Core i7 10700K ($374)
Intel Core i5 10600K ($262)
CPU Cooler Noctua NH-U12S
Motherboard Gigabyte Z490 Vision D
RAM 4x DDR4-2933 16GB (64GB total)
(Set to 2666MHz for 10600K testing)
AMD Ryzen Test Platform
CPU

AMD Ryzen 9 3950X ($749)
AMD Ryzen 9 3900X ($499)

CPU Cooler Noctua NH-U12S
Motherboard Gigabyte X570 AORUS ULTRA
RAM 4x DDR4-2933 16GB (64GB total)
Intel 9th Gen Test Platform
CPU

Intel Core i9 9900K ($488)
Intel Core i7 9700K ($374)

CPU Cooler Noctua NH-U12S
Motherboard Gigabyte Z390 Designare
RAM 4x DDR4-2666 16GB (64GB total)
AMD Threadripper 3rd Gen Test Platform
CPU AMD TR 3990X ($3,990)
AMD TR 3970X ($1,999)
AMD TR 3960X ($1,399)
CPU Cooler Noctua NH-U14S TR4-SP3
Motherboard Gigabyte TRX40 AORUS PRO WIFI
RAM 4x DDR4-2933 16GB (64GB total)
Intel X-10000 Series Test Platform
CPU Intel Core i9 10980XE ($979)
Intel Core i9 10940X ($784)
Intel Core i9 10920X ($689)
Intel Core i9 10900X ($590)
CPU Cooler Noctua NH-U12DX i4
Motherboard Gigabyte X299 Designare EX
RAM 4x DDR4-2933 16GB (64GB total)
Shared PC Hardware/Software
Video Card NVIDIA GeForce RTX 2080 Ti 11GB
Hard Drive Samsung 960 Pro 1TB
Software Windows 10 Pro 64-bit (version 1909)
Mac Pro (2019) iMac Pro
CPU 28‑core Intel Xeon W 2.5GHz 14-core Intel Xeon W 2.5GHz
RAM 96GB DDR4 ECC 64GB 2666MHz DDR4 ECC
Video Card Radeon Pro Vega II Duo 2x32GB Radeon Pro Vega 64 16GB
Hard Drive 1TB SSD storage 1TB SSD
OS Mac OS X (10.15.4)
Current Price $19,599 $7,549

*All the latest drivers, OS updates, BIOS, and firmware applied as of March 30th, 2020

In order to see how each of these configurations performs in After Effects, we will be using our PugetBench for After Effects V0.9 benchmark and After Effects 2020 (17.0.5). This benchmark version includes the ability to upload the results to our online database, so if you want to know how your own system compares, you can download and run the benchmark yourself.

One thing we do want to note is that due to COVID-19 impacting access to our testing hardware and platforms, we are reusing the Intel X-series, AMD Threadripper, and Mac results from our previous After Effects article: After Effects performance: PC Workstation vs Mac Pro (2019). Reusing old results is actually extremely common for hardware reviews, although we normally re-do all our testing to see if newer BIOS, driver, Windows update, and application versions change the results. In this case, however, we are going to simply have to be OK with a bit of a mix of old and new results.

We also found that the pre-launch motherboards we received from Gigabyte (and multiple other manufacturers) were not using Intel's specified power limits in their default BIOS settings. This isn't anything new, but now that Intel is being more aggressive about adding cores and pushing the frequency, this is resulting in much higher power draw (and heat) than you would expect from a 125W processor - often resulting in 100c temperatures after only a few seconds of load. Because of this, we decided to manually set the PL1 and PL2 power limits in the BIOS. We used a value of 125W for the PL1 setting on all three Intel 10th Gen CPUs we tested along with the following PL2 limits according to Intel's specifications:

  • Core i9 10900K: 250W
  • Core i7 10700K: 229W
  • Core i5 10600K: 182W

Setting these power limits made our Noctua NH-U12S more than enough to keep these CPUs properly cooled and helps match our philosophy here at Puget Systems of prioritizing stability and reliability over raw performance in our workstations.

Benchmark Results

While our benchmark presents various scores based on the performance of each test, we also like to provide the individual results for you to examine. If there is a specific task that is a hindrance to your workflow, examining the raw results for that task is going to be much more applicable than the scores that our benchmark calculated.

Feel free to skip to the next sections for our analysis of these results to get a wider view of how each configuration performs in After Effects.

Intel Core 10th Gen vs AMD Ryzen 3rd Gen After Effects Benchmark Results

Benchmark Analysis: Intel Core 10th Gen vs AMD Ryzen 3rd Gen

To start off our analysis of the Intel 10th Gen desktop processors, we are going to look at the performance in After Effects versus AMD's 3rd Gen Ryzen processors. This is likely to be what the majority of readers are going to be interested in, so we decided to pull these results out from the full slew of results that are in the next section.

Since After Effects doesn't scale particularly well with a higher number of CPU cores, you generally don't see much of a performance difference once you get to around the AMD Ryzen 7 or Intel Core i7 level since those CPUs tend to have similar single-core boost performance. You can see this in the chart above as only the Core i5 10600K has a significantly different overall score than the other CPUs we tested.

However, if we dig into the results in more detail, there are some nuances that are not apparent from the overall score. If you look at the RAM preview score (the second chart), the new Intel Core i9 10900K and i7 10700K are about 5% faster than the AMD Ryzen 9 3900X and 3800X respectively. In addition, the Intel 10th Gen CPUs are also about 6% faster than their AMD counterparts for rendering. On the other hand, the AMD Ryzen 3rd Gen processors are anywhere from 3-8% faster than the Intel Core i9 10900K and i7 10700K for tracking.

What this means is that for most people, the Intel 10th Gen processors are likely a better pick since they are marginally faster (around 6%) than AMD Ryzen 3rd Gen for RAM preview and rendering. But if you do a ton of tracking, you may want to opt for an AMD Ryzen 3rd Gen CPU since they are slightly faster for those tasks.

How does Intel 10th Gen stack up overall?

Looking at how the Intel 10th Gen processors compare against a wider range of CPUs, there are a couple of key points we want to note:

First, compared to the previous 9th Gen processors, we are looking at about a 5% performance gain on average with the new 10th Gen models. The Core i7 10700K was a bit above the average with a 7% performance gain overall, while the Core i9 10900K only showed a small 2% performance gain over the Core i9 9900K.

Next, relative to the new Intel Core i9 10900K, the Intel X-10000 Series processors are in general about 5% slower in After Effects. Depending on your workflow, an Intel X-series may still be the right option for you, but just be aware that if After Effects performance is a significant bottleneck for your work, you may want to opt for the much less expensive Core i9 10900K or i7 10700K over a more expensive Intel processor. AMD's Threadripper 3960X, however, is about 10% faster than the Core i9 10900K. Considering that the 3960X is almost three times the price of the Intel Core i9 10900K, that is a pretty hefty investment to make for a modest increase in performance.

Lastly, compared to the Apple systems we have available, our Core i9 10900K configuration was about 7% faster than the $20k Mac Pro, or about 22% faster than the $7.5K iMac Pro.

Is the Intel Core 10th Gen or AMD Ryzen 3rd Gen better for After Effects?

Between the Intel 10th Gen and AMD Ryzen 3rd Gen CPUs, we give the edge to Intel due to their roughly 6% higher performance for RAM preview and rendering. The AMD Ryzen 3rd Gen processors tend to be around 5% faster for tracking, however, which may make them the slightly better option depending on the type of work you tend to do in After Effects.

Overall, this makes the Intel Core i9 10900K our new go-to CPU recommendation for After Effects. The Core i7 10700K is only be a few percent slower than the Core i9 10900K, however, so many may want to go with the more affordable Core i7 model to save a bit of money without sacrificing much performance. There is also a case to be made for the AMD Threadripper 3960X which is about 10% faster than the Core i9 10900K, although given it's much higher cost you are likely better off with the Core i9 10900K and spending the cost savings on more RAM, faster storage, or other system upgrades that can make a bigger difference for overall system performance.

Keep in mind that the benchmark results in this article are strictly for After Effects and that performance will vary widely in different applications. If your workflow includes other software packages (we have similar articles for Premiere Pro, Photoshop, and Lightroom Classic), you need to consider how the system will perform in those applications as well. Be sure to check our list of Hardware Articles to keep up to date on how all of these software packages (and more) perform with the latest CPUs.

Looking for an After Effects Workstation?

Puget Systems offers a range of poweful and reliable systems that are tailor-made for your unique workflow.

Configure a System!

Labs Consultation Service

Our Labs team is available to provide in-depth hardware recommendations based on your workflow.

Find Out More!
Tags: Intel 9th Gen, Intel X-series, AMD Ryzen 3rd Gen, Intel X-10000, Apple Mac Pro, Apple iMac Pro, AMD Threadripper 3rd Gen, Intel 10th Gen, i9 10900K, i7 10700K, i5 10600K, After Effects
CakeInMotion

This is great. I've noticed that in previous results using 0.52b of the benchmark tool.

Overall Score:

3900x was 1019

3800x was 983
3700x was 970

now

3800x is 1056
3900x is 1045
3700x is 1039

The "tracking score" caused this change but I don't know why.
Can you tell me why the order was changed? Is it because of the new updates of bios, windows updates and processors updates Or this is related to something with the tool its self?

Posted on 2020-05-20 23:20:46

All of the above really - that is why we prefer to not re-use old results and redo all the testing for each article.

Also, all of those results as pretty close together so that part of it is just normal variations between runs.

Posted on 2020-05-21 01:06:56
Ahmad Akbar

Hi may i using the Benchmark Analysis pictures for my video on YouTube? i need its, please..

Posted on 2020-05-30 14:07:37
Robert Zhao

Hi there. This article is pretty helpful, but what I'm intersted more is the render score with 3rd party plugins like after codes or a chinese software called aeturbo. Could you guys do a testing for that? Because usually after effects won't be able to use all the processor powers, but with 3rd party plugins, it acatully open multiple ae programs and render as a png format for single frame, then start to render as a video. Usually when I work with this plugin, the render time is saved about 50% compare to after effects itself.
So I am pretty interested about that.

Posted on 2020-06-26 14:28:32

Plugins are something we do want to tackle more in the future, but if you are just talking about using AERender (either directly or via a plugin), we do have results for that. We don't include it all the time in our articles because it isn't used as widely (and may become obsolete soon when AE adds their new multi-threading).

The last article we had it in was https://www.pugetsystems.co...

Posted on 2020-06-26 16:40:59
Robert Zhao

Thanks.

Posted on 2020-06-26 17:07:47
Oscar H.

I wonder if using 3200Mhz RAM on Ryzen CPUS would make up for the 5-6% difference in performance.

Posted on 2020-09-02 08:12:51

Last time we tested, going from DDR4-3000 (close enough to 2933) to DDR4-3200 resulted in an overall increase in performance of 2% with a Ryzen 3900X. https://www.pugetsystems.co... . That is pretty close to the margin of error for real-world testing like this, which means that the difference shouldn't be noticeable at all.

Posted on 2020-09-02 15:48:13
Oscar H.

Oh! thanks a lot for the answer. I wished that somehow it could be possible to get the same performance out of a cheaper CPU, but Intel's higher-than-5GHz clockspeeds really set the pace for After Effects.

Also I didn't know that RAM freqs needed to be lower if you were using 4 sticks with Ryzen (learnt that from the comments above).

Posted on 2020-09-02 21:44:52
CakeInMotion

Hey Matt,
So what actually these results mean when it comes to the time consumed by Ae? i.e. How to interoperate these results in contrast to time? for example if a "X" processor got 750 and a "Y" got 1000 on the benchmark, what dose that means in regard to the time needed to finish the render?

Posted on 2020-09-11 23:37:30

The scores are all relative to the render/playback FPS, so an increase of ~30% (750->1000) should equate to a roughly 30% reduction in render times. So a render that would take 12 minutes with processor X would take around 7 minutes with processor Y.

Posted on 2020-09-14 17:46:07
CakeInMotion

Thanks very much.

Posted on 2020-09-17 05:50:05
Vedran Klemen

You should test After Effects 2014 for multi core rendering since newer versions doesnt support multi threading..

Posted on 2020-09-12 16:46:39

You can't even download AE 2014 anymore - Creative Cloud only goes back a couple versions and that is more than 5 years old at this point. Adobe did tease improved multi-core features at a few of the sessions during the last Adobe Max, so hopefully we'll see something soon!

Posted on 2020-09-14 17:44:42
