Cinema 4D: AMD Ryzen 5000 Series Rendering Performance

Written on November 5, 2020 by William George
Share:

TL;DR: AMD Ryzen 5000 Series Processors for Cinema 4D

The fantastic single-threaded performance of these new Ryzen processors will make them excellent for working with modeling, animation, and physics in Cinema 4D - while also offering solid rendering speeds, especially considering their price points.

For pure rendering workloads, however, AMD's Threadripper line is faster yet (and more expensive). Nothing in Intel's Core or Core X series can compete here. It is worth noting that Cinema 4D also supports other rendering engines via plug-ins, and you can potentially get more performance with GPU-based rendering by combining multiple video cards.

Introduction

AMD's latest mainstream processor family, the Ryzen 5000 Series, has launched with direct upgrades to several (but not all) of their most popular Ryzen 3rd Gen chips. These new models cover from 6 to 16 cores, and utilize the updated Zen 3 microarchitecture which brings substantial improvements to instructions per clock (IPC). Even though core counts and cache sizes are not increasing, the overall performance of these new CPUs is dramatically faster than both previous generations and competing processor designs.

Cinema 4D AMD Ryzen 5000 Series

For this article, we are looking at how the new AMD Ryzen 5000 Series processors compare to a host of other currently-available models: AMD's previous Ryzen 3000 Series, their high-end desktop (HEDT) Threadrippers, and both Intel's mainstream Core and HEDT Core X lines. The focus of this article is primarily on rendering performance in Cinema 4D, but we will also look at single-threaded performance since it is more indicative of how modeling, animation, and physics behave in the viewport. Thankfully, Maxon provides a free, public benchmark in the form of Cinebench - and we run the two most recent revisions to gather our data. More info about those tools and how we use them are available in the Test Methodology section.

Looking for a Cinema 4D Workstation?

Puget Systems offers a range of powerful and reliable systems that are tailor-made for your unique workflow.

Configure a System!

Labs Consultation Service

Our Labs team is available to provide in-depth hardware recommendations based on your workflow.

Find Out More!

Test Setup

Listed below are the specifications of the systems we used for our testing:

AMD Ryzen Test Platform
CPU AMD Ryzen 9 5950X ($799)
AMD Ryzen 9 3950X ($749)
AMD Ryzen 9 5900X ($549)
AMD Ryzen 9 3900XT ($499)
AMD Ryzen 7 5800X ($449)
AMD Ryzen 7 3800XT ($399)
AMD Ryzen 5 5600X ($299)
AMD Ryzen 5 3600XT ($249)
CPU Cooler Noctua NH-U12S
Motherboard Gigabyte X570 AORUS ULTRA *
RAM 4x DDR4-3200 16GB (64GB total)
Intel 9th Gen Test Platform
CPU Intel Core i9 10900K ($488)
Intel Core i7 10700K ($374)
Intel Core i5 10600K ($262)
CPU Cooler Noctua NH-U12S
Motherboard Gigabyte Z490 Vision D
RAM 4x DDR4-3200 16GB (64GB total)
AMD Threadripper 3rd Gen Test Platform
CPU AMD TR 3990X ($3,990)
AMD TR 3970X ($1,999)
AMD TR 3960X ($1,399)
CPU Cooler Noctua NH-U14S TR4-SP3
Motherboard Gigabyte TRX40 AORUS PRO WIFI
RAM 4x DDR4-3200 16GB (64GB total)
Intel X-10000 Series Test Platform
CPU Intel Core i9 10980XE ($979)
CPU Cooler Noctua NH-U12DX i4
Motherboard Gigabyte X299 Designare EX
RAM 4x DDR4-2933 16GB (64GB total)
Shared PC Hardware/Software
Video Card NVIDIA GeForce RTX 3080 10GB
Hard Drive Samsung 960 Pro 1TB
Software Windows 10 Pro 64-bit
Cinebench R15
Cinebench R20

*Pre-launch BIOS only has AGESA 1.0.8, but AMD says AGESA 1.1.0 should come soon - which may further improve performance

Test Methodology

The primary focus of Cinebench is on measuring system performance using the default CPU-based renderer in Cinema 4D. Normally, all cores / threads a CPU has are utilized - but there is an option to run the test on a single core as well. To try and paint a more complete picture of performance, we have run both multi- and single-core modes, and in both the latest Cinebench R20 as well as the older R15 release. The multi-core results will be shown first, as they are indicative of what real-world rendering performance will be like with each of these processors. Below that, the single-core results will give a rough indication of how these CPUs would fare when working with modeling, animation, and physics in the viewport.

Benchmark Results

There are a lot of processors in this round-up, so we are color-coding the results to make them easier to sift through:

  • Light red with glow = New AMD Ryzen 5000 Series processors
  • Light red (without glow) = Older AMD Ryzen 3rd Gen models
  • Dark red = AMD HEDT Threadripper 3rd Gen CPUs
  • Light blue = Intel mainstream Core 10th Gen processors
  • Dark blue = Intel HEDT Core X 10000 Series CPUs

Results are listed from fastest to slowest (top to bottom), and split up by multi- versus single-threaded test modes.

Multi-core Rendering Performance

Single-threaded Performance

Analysis

The big increase in instructions per clock that AMD has touted for these processors is most apparent in the single-threaded performance charts. The Ryzen 9 5950X is a full 20% faster with just one active core than the 3950X was in Cinebench R20, and the other three new 5000 Series models see gains of 15-20% over the previous generation. In the older R15 version of the test, the gains are even higher at 20-30%. Not only do the new Ryzen models beat their predecessors, but they also surpass all of the Intel processors we tested. This isn't a perfect test of viewport behavior, but it does show that AMD has outpaced Intel for single-threaded performance - and it is safe to assume that will translate to a better experience with modeling, animation, and physics in Cinema 4D.

Actual CPU rendering is extremely well threaded, though, so for that we need to look at the multi-core results. The generational increase here isn't quite as extreme, but most of the Ryzen 5000 Series still gain 10-15% over the older models. They also roundly beat all of the Intel Core and especially Core X processors in terms of price:performance ratio (value for the money, effectively)... with the possible exception of the Core i9 10900K edging out the slightly less expensive Ryzen 7 5800X. That is the top of Intel's mainstream Core series, though, pitted against the Ryzen model that is third from the top of AMD's new line-up; a rather hollow victory, if it is one at all. One group of processors these new chips cannot beat, however, is AMD's own Threadripper line. Those have far higher core counts, so even without being as fast per-core they still excel at rendering.

Are AMD's Ryzen 5000 Series Processors Good for Cinema 4D?

The fantastic single-threaded performance of these new Ryzen processors will make them excellent for working with modeling, animation, and physics in Cinema 4D - while also offering solid rendering speeds, especially considering their price points. For pure rendering workloads, however, AMD's Threadripper line is faster yet (and more expensive).

Looking for a 3D Design Workstation?

Puget Systems offers a range of poweful and reliable systems that are tailor-made for your unique workflow.

Configure a System!

Labs Consultation Service

Our Labs team is available to provide in-depth hardware recommendations based on your workflow.

Find Out More!
