Intel Core i9 7900X 3.3GHz Ten Core 13.37MB 140W

CPU

Intel Core i9 7900X 3.3GHz Ten Core 13.37MB 140W Picture 43128

Background on Intel Core X-series CPU

Intel's enthusiast-class Core i7 and i9 processors represent the top-end of their consumer CPU line, and bridge the gap between the more mainstream chips and the Xeon server-grade models. These processors range from six to eighteen cores, with base clock speeds of 2.6 to 3.6GHz - and turbo boost speeds of 4GHz or more. The combination of high core counts with high clock frequencies allow these processors to excel at both single and multi-threaded workloads.

William George (Puget Labs)
William George (Puget Labs) Says:
These processors were codenamed Skylake-X, when first announced, but Intel seems to have standardized on calling them Core X-series processors. There are also some Kaby Lake-X chips that share the same socket and are compatible with some of the same motherboards, but they have fewer memory channels and PCI-E lanes, so to avoid confusion and situations where lots of motherboard features are disabled we are not currently offering them.

Model: Intel BX80673I97900X

Specifications:
spacer
Product Line  Core i9
Code Name  Skylake-X
Socket  2066
Process  14 nm
Number of Cores  10
Clock Speed  3.30 GHz
Hyperthreading  Yes
Turbo Boost  Yes
Max. Turbo Boost  4.5 GHz
All-Core Turbo Boost  4.00 GHz
Bus Type  DMI3
Thermal Output  140 W
PCI-E Lanes  44
Cache
Smart Cache  13.75MB
Memory Specification
Memory Type  DDR4
Maximum Frequency  2666
ECC Support  No
Advanced Technologies
vPro  No
Virtualization Technology (VT-x)  Yes
Virtualization Technology for Directed I/O (VT-d)  Yes
Trusted Execution Technology  No

  • Intel Core i9 7900X 3.3GHz Ten Core 13.37MB 140W Drivers
    • ITBM.zip
      Version 1.0.0.1031 Released 05/30/17
      For Win7_64, Win8_64, Win10_64

Configure a custom workstation with the Intel Core i9 7900X 3.3GHz Ten Core 13.37MB 140W.
