Intel Xeon E3-1225 V6 3.3Ghz Quad Core 8MB 73W
CPU
Background on Intel Xeon E3 (V6 / Kaby Lake) CPU
Intel's E3 Xeon workstation and server processors have been updated to the "V6" series, which is based off Intel's Kaby Lake CPU line. This is the same technology found in the seventh generation of the Core processor series, and just like those desktop chips these Xeons provide a performance boost compared to their predecessors. Both performance-per-clock and the built-in graphics capabilities are improved, compared to previous generations, and since power usage remained similar that means efficiency (performance-per-watt) increased as well.
Model: Intel BX80677E31225V6
Specifications:
Specifications:
| Product Line | Xeon |
| Code Name | Kaby Lake-S |
| Socket | 1151 |
| Process | 14 nm |
| Number of Cores | 4 |
| Clock Speed | 3.3 GHz |
| Hyperthreading | No |
| Turbo Boost | Yes |
| Max. Turbo Boost | 3.7 GHz |
| Bus Type | DMI3 |
| Thermal Output | 73 W |
| PCI-E Lanes | 16 |
| Cache | |
| L2 | 4 x 256KB |
| Smart Cache | 8MB |
| Onboard Graphics | |
| Processor Type | Intel HD Graphics P630 |
| Core Speed | 350 Mhz |
| DirectX Version | 12 |
| # of Displays Supported | 3 |
| Memory Specification | |
| Memory Type | DDR4 |
| Maximum Frequency | 2400 |
| ECC Support | Yes |
| Advanced Technologies | |
| vPro | Yes |
| Virtualization Technology (VT-x) | Yes |
| Virtualization Technology for Directed I/O (VT-d) | Yes |
| Trusted Execution Technology | Yes |
- Intel Xeon E3-1225 V6 3.3Ghz Quad Core 8MB 73W Drivers
- win64_154519.4678.zip
Version 15.45.19.4678 Released 05/30/17
For Win7_64, Win8_64, Win10_64
- win64_154519.4678.zip
Configure a business workstation with the Intel Xeon E3-1225 V6 3.3Ghz Quad Core 8MB 73W.
