Intel Xeon E5-2697 V4 2.3GHz Eighteen Core 45MB 145W

CPU

Intel Xeon E5-2697 V4 2.3GHz Eighteen Core 45MB 145W Picture 38904

Background on Intel Xeon E5 2600 V4 CPU

Intel's E5 2600 V4 series of Xeon processors are based on the Broadwell EP architecture, and the updated socket 2011-3 for mounting. This brings technology improvements from the enthusiast Broadwell-E series into the server and workstation areas, and combines them with the ability to run two CPUs on a single motherboard.

For the most part this generation is geared toward more cores per CPU, but with slightly lower clock speeds. At the same time, though, performance per clock has been improved - and the inclusion of instruction sets like AVX2 and FMA3 can mean massive increases to processing speed in select applications.


Model: Intel BX80660E52697V4

Specifications:
spacer
Product Line  Xeon
Code Name  Broadwell-EP
Socket  2011-3
Process  14 nm
Number of Cores  18
Clock Speed  2.3 GHz
Hyperthreading  Yes
Turbo Boost  Yes
Max. Turbo Boost  3.6 GHz
All-Core Turbo Boost  2.8 GHz
Bus Type  DMI2
QPI Speed  9.6 GT/s
Thermal Output  145 W
PCI-E Lanes  40
Cache
Smart Cache  45MB
Memory Specification
Memory Type  DDR4
Maximum Frequency  2400
ECC Support  Yes
Advanced Technologies
vPro  Yes
Virtualization Technology (VT-x)  Yes
Virtualization Technology for Directed I/O (VT-d)  Yes
Trusted Execution Technology  Yes
TSX-NI  No

  • Intel Xeon E5-2697 V4 2.3GHz Eighteen Core 45MB 145W Utility

Configure a custom workstation with the Intel Xeon E5-2697 V4 2.3GHz Eighteen Core 45MB 145W.
