Intel Xeon W-2225 4.1GHz 4 Core 8.25MB 105W


Intel Xeon W-2225 4.1GHz 4 Core 8.25MB 105W  Picture 58110

Background on Intel Xeon W-2200 Series

Intel's Xeon W series of processors are based on the Cascade Lake W architecture, which is similar to Cascade Lake X but has been adapted for workstation and server use. To that end, these CPUs have support for Registered ECC memory, higher RAM capacities, and a slightly increased PCI-E lane count compared to the enthusiast Core X series. The same socket 2066 is used, but in order to properly support the added feature set a different chipset / motherboard is required for the Xeon W processors.

Product Line  Xeon W
Code Name  Cascade Lake-W
Socket  2066
Process  14 nm
Total Number of Cores  4
Base Clock Speed  4.10 GHz
Hyperthreading  Yes
Turbo Boost  Yes
Max. Turbo Boost  4.60 GHz
All-Core Turbo Boost  4.50 GHz
Bus Type  DMI3
Thermal Output  105 W
PCI-E Lanes  48
Max Temperature  86 C
Smart Cache  8.25MB
Memory Specification
Memory Type  DDR4
Maximum Frequency  2933
ECC Support  Yes
Registered Support  Yes
Advanced Technologies
vPro  Yes
Virtualization Technology (VT-x)  Yes
Virtualization Technology for Directed I/O (VT-d)  Yes
Trusted Execution Technology  Yes

Max memory speed is reduced to 2666MHz when configured with two DIMMs per channel.
