Intel Xeon W-2255 3.7GHz 10 Core 19.25MB 165W
CPU
Background on Intel Xeon W-2200 Series
Intel's Xeon W series of processors are based on the Cascade Lake W architecture, which is similar to Cascade Lake X but has been adapted for workstation and server use. To that end, these CPUs have support for Registered ECC memory, higher RAM capacities, and a slightly increased PCI-E lane count compared to the enthusiast Core X series. The same socket 2066 is used, but in order to properly support the added feature set a different chipset / motherboard is required for the Xeon W processors.
Specifications:
| Product Line | Xeon W |
| Code Name | Cascade Lake-W |
| Socket | 2066 |
| Process | 14 nm |
| Number of Cores | 10 |
| Clock Speed | 3.70 GHz |
| Hyperthreading | Yes |
| Turbo Boost | Yes |
| Max. Turbo Boost | 4.50 GHz |
| Intel Turbo Boost Max 3.0 | 4.70 GHz |
| All-Core Turbo Boost | 4.30 GHz |
| Bus Type | DMI3 |
| Thermal Output | 165 W |
| PCI-E Lanes | 48 |
| Max Temperature | 86 C |
| Cache | |
| Smart Cache | 19.25MB |
| Memory Specification | |
| Memory Type | DDR4 |
| Maximum Frequency | 2933 |
| ECC Support | Yes |
| Registered Support | Yes |
| Advanced Technologies | |
| vPro | Yes |
| Virtualization Technology (VT-x) | Yes |
| Virtualization Technology for Directed I/O (VT-d) | Yes |
| Trusted Execution Technology | Yes |
| TSX-NI | Yes |
Max memory speed is reduced to 2666MHz when configured with two DIMMs per channel.
Configure a scientific workstation with the Intel Xeon W-2255 3.7GHz 10 Core 19.25MB 165W.
